S&P CADB-HE BASIC Series Manual page 29

Nº Type of register
Reg.
Fans operation mode VAV
50 Holding Register
6 Holding Register
7 Holding Register
8 Holding Register
10 Holding Register
11 Holding Register
12 Holding Register
13 Holding Register
14 Holding Register
15 Holding Register
16 Holding Register
17 Holding Register
18 Holding Register
19 Holding Register
20 Holding Register
21 Holding Register
22 Holding Register
51 Holding Register
52 Holding Register
53 Holding Register
54 Holding Register
3 Discret input
23 Holding Register
24 Holding Register
Description Range
Selected speed 1
2
3
4
Low speed 0,5 - 5
Medium speed 3 - 8
High speed 5 - 10
Type of sensor 0
1
2
3
4
Range PPM 0 - 4000
Temperature Range 0 - 80
Rel.Humidity range 0 - 100
Range 0-10V 0 - 10
Setpoint PPM 0 - End of
range
Setpoint ºC 0 - End of
range
Setpoint % humidity 0 - End of
range
Setpoint 0-10V 0 - End of
range
Offset regulation 0 - End of
(+/-) PPM range
Offset regulation 0 - End of
(+/-) ºC range
Offset regulation 0 - End of
(+/-) % humidity range
Offset regulation 0 - End of
(+/-) 0-10V range
Alarm limit PPM 0 - End of
range
Alarm limit ºC 0 - End of
range
Alarm limit % 0 - End of
humidity range
Alarm limit 0-10V 0 - End of
range
Status alarms 0
1
Minimum output 0 - 5
Maximum output 5 - 10
Data Default
value
Low speed 1
Medium
speed
High speed
Automatic
Volts 3,5
Volts 6
Volts 9,5
Without 0
sensor
CO2
Temperature
Relative
humidity
0-10V external
control
CO PPM 2000
2
ºC 50
% Humidity 100
Volts 10
PPM 1100
ºC 25
% Humidity 50
Volts 5
PPM 400
ºC 2
% Humidity 5
Volts 2,5
PPM 1600
ºC 28
% Humidity 70
Volts 10
Alarm not 0
active
Alarm active
Volts 2
Volts 10
R/W Comments
R/W
R/W
R/W
R/W
R/W
R/W If type sensor = 1
R/W If type sensor = 2
R/W If type sensor = 3
R/W If type sensor = 4
R/W If type sensor = 1
R/W If type sensor = 2
R/W If type sensor = 3
R/W If type sensor = 4
R/W If type sensor = 1
R/W If type sensor = 2
R/W If type sensor = 3
R/W If type sensor = 4
R/W If type sensor = 1
R/W If type sensor = 2
R/W If type sensor = 3
R/W If type sensor = 4
R
R/W
R/W
