6.6. CONFIGURATIONS

CADB/T-HE BASIC standard confi guration
From these confi gurations there are multiple variables that can be performed by the professional ins-
taller quickly and easily.
Panel replacement process
The CADB-HE heat recovery units are available in two confi gurations LH and RH in the horizontal mo-
dels and LV, RV in vertical models.
Horizontal
Factory confi guration
LH
RH
Vertical
Factory confi guration
LV
RV
Examples of some of the confi gurations that is possible to obtain from
factory confi guration
Examples of some of the confi gurations that is possible to obtain from
factory confi guration
EXHAUST AIR FRESH AIR
EXHAUST AIR FRESH AIR
