ETC ESR3 Series Installation Manual
  1. Manuals
  2. Brands
  3. ETC Manuals
  4. Racks & Stands
  5. ESR3 Series
  6. Installation manual

ETC ESR3 Series Installation Manual

Sensor 3 ce rack
Hide thumbs

Advertisement

Quick Links

Download this manual
®
Sensor
3 CE Rack (ESR3 Series)
Installation Manual
Revision H
This product is intended for professional use only.
Read this entire document before using this product.
Copyright © 2016 Electronic Theatre Controls, Inc.
All rights reserved. Product information and specifications subject to change.
Part Number: 7144M2100 Rev: H
Released: October 2016

Advertisement

loading

Related Manuals for ETC ESR3 Series

Summary of Contents for ETC ESR3 Series

  • Page 1 ® Sensor 3 CE Rack (ESR3 Series) Installation Manual Revision H This product is intended for professional use only. Read this entire document before using this product. Copyright © 2016 Electronic Theatre Controls, Inc. All rights reserved. Product information and specifications subject to change.
  • Page 2 ® ® ET C a n d S e n s o r ar e eit h er r egist er ed tr ade ma rk s or t ra d em ar ks of E l ec tr onic T he a tr e Cont rols, I n c .
  • Page 3 Contacting ETC ........6...
  • Page 4 Energising the System .......29 Contacting ETC ........30 Sensor3 Installation Checklist .
  • Page 5 Warnings WARNING: • INCORRECT CONNECTION MAY CAUSE DAMAGE OR INJURY. (GB) • FOR PROFESSIONAL USE ONLY. • THIS EQUIPMENT MUST ONLY BE CONNECTED AND OPERATED BY AUTHORISED PERSONNEL. • READ NOTICES AND WARNINGS IN PRODUCT DOCUMENTATION BEFORE USE. • WARNING: HIGH LEAKAGE CURRENT; THIS EQUIPMENT MUST BE GROUNDED.
  • Page 6 VAROITUS: • KYTKENTÄVIRHE VOI AIHEUTTAA LAITTEEN RIKKOUTUMISEN TAI HENGENVAARAN. (FI) • VAIN AMMATTIKÄYTTÖÖN. • LAITTEEN SAA KYTKEÄ AINOASTAAN KOULUTETTU, ASIANSA OSAAVA HENKILÖ. • LUE VARIOTUKSET LAITTEEN KÄYTTÖOHJEISTA ENNEN KÄYTTÖÄ. • VAROITUS: SUURI VUOTOVIRTA, LAITE ON EHDOTTOMASTI MAADOITETTAVA. • KYTKE VIRRANSYÖTTÖ POIS AINA ENNENKUIN POISTAT LAITTEEN SUOJUKSET.
  • Page 7 ATTENZIONE: • L’ERRATA CONNESSIONE PUO CAUSARE DANNI A COSE E A PERSONE. (IT) • SOLO PER USO PROFESSIONALE. • QUESTO EQUIPAGGIAMENTO DEVE ESSERE COLLEGATO O AXIONATO SOLAMENTE DA PERSONALE AUTORIZZATO. • LEGGERE GLI AVVISI E LE SEGNALAZIONI CONTENUTI NELLA DOCUMENTAZIONE DEL PRODOTTO PRIMA DELL’USO.
  • Page 8 VARNING: • FELAKTIG ANSLUTNING KAN ORSAKA OLYCKOR ELLER SKADOR. (SE) • FÖR PROFFESSIONELT BRUK. • UTRUSTNINGEN FÄR ENDAST ANVÄNDAS OCH ANSLUTAS AV SÄRSKILT INSTRUERAD PERSONAL. • LÄS INSTRUKTIONER I DOKUMENTATIONEN FÖRE ANVÄNDING. • VARNING: LIVSFARLIG SPÄNNING. UTRUSTNINGEN MÄSTE VARA SKYDDSJORDAD. •...
  • Page 9 • tells you how to finish the installation of your rack. Note that the operations in this chapter should be performed by ETC trained technicians. When viewing this document in electronic form (.pdf file) with Adobe Acrobat Reader, blue italicised...
  • Page 10 If you are having difficulties, your most convenient resources are provided in this installation manual. To search more widely, try the ETC website at www.etcconnect.com. If none of these resources is sufficient, contact ETC Technical Services directly at one of the offices identified below.
  • Page 11 Dimmer racks installed without an accessible power disconnect device cannot be serviced or operated safely. Energising the System Sensor3 racks should only be energised by an authorised ETC representative. Wiring errors in unauthorised installations may endanger personnel or cause system damage and failure. WARNING: Do not attempt to energise the system without proper approval.
  • Page 12 Where to Mount the Rack Sensor3 dimmer racks require 25 cm of top clearance for proper airflow through the cabinet. To allow the door to open sufficiently to install and remove modules, install the rack with 150 mm 250 mm 41 cm of front clearance and 15 cm clearance to the left of the door hinge from walls or other equipment.
  • Page 13 Chapter 2 Installation of Racks Mounting the Rack • ESR3-12 racks are normally wall-mounted. • ESR3-24 racks can be mounted to a wall or floor-mounted on an optional pedestal. • ESR3-36 and ESR3-48 racks are floor standing. Mounting Racks on a Wall (ESR3-12 and ESR3-24) Appendix A: Sensor3 CE Rack The wall must be strong enough to hold the racks.
  • Page 14 Installing ESR3-36 and ESR3-48 Racks on the Floor Figure 1: Sensor3 rack clearances on Step 1: Determine where your rack will be installed using page 8 and use the appropriate diagram from Figure 2 to mark your mounting holes. Note: Sensor3 racks of the same size are the single exception to the 15 cm left clearance requirement.
  • Page 15 32 mm 79 mm 32 mm 294 mm 79 mm 480 mm 294 mm 511 mm 404 mm 436 mm Dia. 10 mm Dia. 10 mm 373 mm 373 mm ESR3-48 Floor mount hole diagram ESR3-36 / ESR3-24 Floor mount hole diagram Figure 2: Hole diagrams for mounting racks to the floor Securing Sensor3 Racks to a Wall Racks installed on the floor or a pedestal can also be secured to a wall for greater stability.
  • Page 16 25 cm 25 cm Note: ETC’s wall mount vibration pads (ETC Part# Figure 3: Positioning a vibration pad on a wall HW6111) attach to racks with the provided bolts that are slightly larger than the top of the keyhole slots.
  • Page 17 Step 7: [Optional] If required, secure the rack to a wall using wall mount vibration pads (ETC Part# HW6111). If the vibration pads have been requested for the installation, they are included with the rack.
  • Page 18 Securing Multiple Racks (Optional) Multiple racks can be connected to each other for greater stability. Note: If you want to install the control cable through the side of the racks, you should remove the side cable knockouts before connecting the rack. Step 1: Use M8 spin lock bolts and lock nuts in the front and at the back to bolt the racks together at the bottom.
  • Page 19 Rack Cabling Access ESR3 racks have removable top and bottom access panels. Top access panel Bottom access panel Figure 7: ESR3 access panels Conduit Connections Step 1: Remove the desired access panel from the rack. Step 2: Cut access holes in the top and bottom access panels. Step 3: Install your cabling into the holes.
  • Page 20 Connect Line Power Wiring ETC recommends routing line (feeder) cables first, load neutral and load earth wires next, and load phase wires last. CAUTION: Line and load wires used with Sensor3 dimming systems must be copper. Do not connections use wire containing aluminium or other metals.
  • Page 21 Chapter 3 Land Load Wires Land Load Wires Dress and connect load wires neatly without leaving extra wire in the rack. Each dimmer has three sets of lugs connected to phase, neutral and earth. Phase and earth lugs are on the right side of the rack, neutral lugs are on the left.
  • Page 22 Step 1: Route the load wires to the rack(s). Step 2: If using Multicore cable, strip back the sheath so that phase, neutral and earth can be corrected to the relevant lugs as shown. Load Neutral (blue Load Phase wires) are landed on (brown wire) load neutral lugs attached to the main...
  • Page 23 Modules with current capacities higher than 15A are prevented from fitting into incorrect slots by the module cutout bar to the left of the rack. If you have supplied a configuration chart to ETC these should be cut out correctly for you; otherwise you will have to cut the bar on site.
  • Page 24 RCD or ND modules, and single pole modules that do not. Normally your rack will be configured by ETC at the factory for the correct module types, however if you have a mixture of modules or you have not been able to supply details of slot allocations you may need to configure some slots on site.
  • Page 25 Installing Three-Slot Dimmer Lug Strips Step 1: Use a Phillips screwdriver to remove the two screws securing the lug strip to the left side of the rack. Step 2: Remove the lug strip and replace it with one containing a three-slot Neutral jumper. Step 3: Secure the strip to the rack with the screws you removed in Step 1.
  • Page 26 Chapter 4 Control and Data Connections Sensor3 racks support a variety of control and data connections on the CEM3 backplane. CEM3 backplanes have connectors for: • Two DMX512 Cables (Universes) • External Panic Circuit Activation and Indication • Remote Redundant Tracking selection switch (Dual Backplane Only) •...
  • Page 27 Running DMX Cable to Racks Note: If the system includes a Panic circuit, stations or Remote Tracking Selection, pull the necessary wires with the data cables to all required racks. Step 1: Remove the desired top, bottom or side conduit knockout from the Figure 3:Side first rack on the left or right of the group of racks.
  • Page 28 • If the connection ends at the rack, turn termination On. • If a data connector is not used, either setting is acceptable. Note: The termination switches should not be set to the “RDM” position unless recommended by ETC. Sensor3 CE Rack (ESR3) Installation Manual...
  • Page 29 Running Ethernet to Racks Sensor3 racks use Ethernet for communication with each other and sometimes for communication with the lighting console. It is therefore important that all racks are linked via Ethernet. This may either be done using an NEFM (Network Electronics Filler Module - A network switch built into the lower slot of one of the racks) or using an external network hub or switch.
  • Page 30 Ethernet Network Termination - RJ45 Connector Step 1: Follow the directions provided in the Ethernet Termination Kit to terminate the incoming CAT5 cable in the RJ45 UTP connector in the surface mounting box. The kit is included with the dimmer rack door. Use the instructions provided with the kit for proper Category 5 cable termination.
  • Page 31 Dual Tracking Remote Select Switch connection (Optional) If desired, a remote switch can be wired to the CEM3 backplane to control CEM3 selection in racks equipped with ETC’s Redundant Tracking CEM3 option. Note: You must supply your own enclosed single-pole double-throw center-off switch to install a remote select switch.
  • Page 32 Station Connection (Optional) Sensor3 racks support ETC’s range of stations. The station network should be wired in Belden 8471 or an equivalent cable. Stations are topology-free. Wiring may be bus, star, loop, home run or any combination of these. To stations...
  • Page 33 ESR3-48AF ESR3-48AFN Energising the System You need ETC approval to apply power to your dimming system. Wiring errors in unauthorised installations may endanger operators or cause system damage and failure. WARNING: Do not attempt to energise the system without proper approval.
  • Page 34 Contacting ETC To obtain ETC approval or for referral to an authorised ETC representative, contact ETC as shown in Contacting ETC page Sensor3 Installation Checklist Appendix B: Sensor3 Installation Checklist, page 37. Following this A checklist is provided in checklist will help ensure that your Sensor3 system operates reliably and without problems. The checklist is a summary version of the steps in this chapter.
  • Page 35 CAUTION: Dimmer rack doors filter and regulate ventilation airflow. Operating without the door can contaminate the rack interior with dust and cause rack modules to overheat. Step 1: Insert the top hinge into the slot on the top of the rack and attach it to the frame with two Phillips head screws (included).
  • Page 36 pin through the washers and into the hole on the lower hinge. Door Washers Door Taper pin Taper pin ESR3-48 lower hinge ESR3-12 lower hinge Figure 4: Installing the bottom taper pin Step 3: Hold the door in place and insert the other taper pin, narrow end down, through the top hinge and washer.
  • Page 37 RISK OF ELECTRIC SHOCK! Power must be turned OFF when you perform this procedure. Step 1: Clean out dust, metal scraps or other debris from the rack interior. ETC recommends vacuuming the rack interior before installing modules. Step 2: Check for loose connections, bare wires or damaged insulation. Step 3: Correct air leaks caused by misaligned or removed panels, empty screw holes, or conduit openings.
  • Page 38 Appendix B: Sensor3 Installation Checklist, Once you have completed installation, please fill in page 37 for the system and return it to ETC. The system will then be covered under the ETC warranty programme. Testing an Installed Sensor3 Rack After finishing installation, use this procedure to perform a functional check.
  • Page 39 Replace the CEM3 and close the rack door. Step 7: An Authorized Service Center (ASC) may now configure the CEM3 processor(s) and test the dimming system using the facility control system. Step 8: Deliver all ETC documentation to the system operator. Finishing Installation...
  • Page 40 Ap p e ndi x A Sensor3 CE Rack Specifications All of the rack specifications apply to all of the ESR3 series of Pollution Degree: 2 racks unless otherwise noted. Complies with Low Voltage Directive 73/23/EC General Electromagnetic Compatibility Directive 89/336/83/EC...
  • Page 41 Sensor3 Installation Checklist CAUTION: This checklist is for use by authorised ETC trained personnel when energising ETC Sensor3 racks. Do not attempt to energise a Sensor3 system unless you are authorised and qualified to do so.  Rack clear of dust and debris ...
  • Page 42 A ppe n di x C Emergency Modules About Emergency Modules Sensor3 CE Emergency modules provide two live outputs, one of which is dimmed or switched, and one of which is live whenever the breaker is turned on. This allows the modules to control battery backed lighting which requires a constant and a switched or dimmed feed.
  • Page 43 Instead, an auxiliary neutral terminal must be fitted to the neutral plate and the loads should be connected to the terminal. If your rack was ordered with Emergency Modules the auxiliary neutral terminal should be factory fitted. If you require an auxiliary neutral terminal, please contact ETC as Contacting ETC...
  • Page 44 Service: (DE) techserv-hoki@etcconnect.com   Hong Kong Tel +852 2799 1220 Service: (Asia) service@etcasia.com   Web: Copyright © 2016 ETC. All Rights Reserved. www.etcconnect.com  7144M2100 Rev H Released 2016-10 Product information and specifications subject to change.   ...
