ETC Mosaic Touchscreen Rack-Mount Kit Installation Manual

ETC Installation Guide
Mosaic Touchscreen Rack-Mount Kit
Overview
The Mosaic Touchscreen Rack-Mount Kit is an accessory mounting option for the 5" or 8"
touchscreen.
Each touchscreen model ships with a universal mounting plate that installs to the rack-mount
panel, allowing touchscreen installation in a horizontal orientation. This guide provides
instructions for installing the rack-mount kit to an equipment rack and the touchscreen mounting
plate to the rack-mount panel.
Refer to the installation guide provided with the touchscreen for touchscreen environment,
electrical, installation, and service instructions.
Note:
Corporate Headquarters n Middleton, WI, USA | +1 608 831 4116
Global Offices n London, UK | Rome, IT | Holzkirchen, DE | Paris, FR | Hong Kong | Dubai, UAE | Singapore
New York, NY | Orlando, FL | Los Angeles, CA | Austin, TX | © 2024 Electronic Theatre Controls, Inc.
Web
Trademark and patent info:
Product information and specifications subject to change. ETC intends this document to be provided in its entirety.
7184M2191 Rev A Released 2024-05
483 mm
19 in
50 mm
1.96 in
121 mm
4.75 in
483 mm
19 in
66 mm
2.6 in
121 mm
4.76 in
Installation must follow all national and local codes for electrical equipment.
etcconnect.com | Support support.etcconnect.com
etcconnect.com/ip
5" Rack-Mount Kit
7184A1523
8" Rack-Mount Kit
7184A1524
| Contact etcconnect.com/contactETC
| Third-party license agreement info: etcconnect.com/licenses
132 mm
5.2 in
177 mm
6.96 in
