ETC Installation Guide
Sensor3 BatteryPack Option
Introduction
This guide illustrates installation of the Sensor3 BatteryPack Option. The BatteryPack Option should be
placed in the vicinity of your Sensor3 dimmer racks.
The BatteryPack Option provides battery power to CEM3 control modules for up to 45 minutes during
power outages, thereby facilitating an instantaneous recovery after power has been restored. Each
BatteryPack Option may be fitted with one or two batteries; each battery feeds one Sensor3 rack.
Required tools
• Flatblade screwdriver
• Precision flatblade screwdriver
• No. 2 Phillips screwdriver
• Small extension (dental) mirror
• Wire strippers for 1.5-2.0 mm
• Wire cutters
Required materials (not provided)
• Appropriate mounting hardware for attaching BatteryPack Option to wall
• 1.5-2.0 mm
• 3/4" or smaller conduit of adequate length for wire run
Procedure
This procedure includes the following sections:
•
•
•
•
•
•
•
Corporate Headquarters
Global Offices
New York, NY | Orlando, FL | Los Angeles, CA | Austin, TX
Web
© 2021 Electronic Theatre Controls, Inc. | Trademark and patent info:
Product information and specifications subject to change. ETC intends this document to be provided in its entirety.
7140M2180 Rev B Released 2021-03
2
(14-18 AWG) wire
2
(14-18 AWG) twisted pair of adequate length for wire run
page 2
page 3
page 4
page 6
page 7
Middleton, WI, USA | +1 608 831 4116
London, UK | Rome, IT | Holzkirchen, DE | Paris, FR | Hong Kong | Dubai, UAE | Singapore
etcconnect.com
| Support
support.etcconnect.com
page 2
| Contact
etcconnect.com/contactETC
etcconnect.com/ip
page 2
Advertisement
Table of Contents
Related Manuals for ETC Sensor 3
Summary of Contents for ETC Sensor 3
- Page 1 | Support support.etcconnect.com | Contact etcconnect.com/contactETC © 2021 Electronic Theatre Controls, Inc. | Trademark and patent info: etcconnect.com/ip Product information and specifications subject to change. ETC intends this document to be provided in its entirety. 7140M2180 Rev B Released 2021-03...
- Page 2 ETC Installation Guide Sensor3 BatteryPack Option Preparation Turn off power to the rack. WARNING: RISK OF ELECTRIC SHOCK! Failure to disconnect all power to the rack before working in the rack could result in serious injury or death. AVERTISSEMENT : Travailler à...
- Page 3 ETC Installation Guide Sensor3 BatteryPack Option Connect the Battery Leads In order to prevent premature battery drain, the battery pack(s) for the BatteryPack Option are shipped with the leads disconnected. You must first open the battery pack(s) and connect the wire leads to the appropriate terminals.
- Page 4 ETC Installation Guide Sensor3 BatteryPack Option Connect Wiring Wiring tasks differ based on whether you are installing one battery pack or two: • One battery pack: Use the instructions that follow to terminate one set of wires between the Rack A (left) side of the BatteryPack Option terminals and the back of the CEM3 backplane.
- Page 5 ETC Installation Guide Sensor3 BatteryPack Option Terminate Wire to CEM3 Backplane Find the 2-pin Phoenix connector (part number J3976-F) included with the BatteryPack Option. Connect the wires from the BatteryPack Option to the 2-pin Phoenix connector using a flatblade precision screwdriver: •...
- Page 6 ETC Installation Guide Sensor3 BatteryPack Option Install Battery Pack(s) Make sure you have connected the battery leads inside of the battery pack before installing it in the Connect the Battery Leads page 3 BatteryPack Option (see Hold the battery pack so that the LED indicators are on the top.
- Page 7 Check the BatteryPack Option LEDs monthly to verify that the batteries are still accepting a charge. If your battery constantly indicates a “CHARGING” state or if the red “CHARGING FAULT” indicator is lit, visit etcconnect.com/contactETC for information on how to contact ETC Technical Services. BatteryPack Option Page 7 of 7...
