Expansion Interface (J1–3)
Three board-to-board connector footprints provide signals for most of the
processor's peripheral interfaces. The connectors are located at the bottom
of the board. For more information about the interface, see
Interface" on page
connectors, contact Samtec.
J3
Part Description
90-position 0.05" spacing, SMT
(
,
,
)
J1
J2
J3
90-position 0.05" spacing
(through hole)
90-position 0.05" spacing
(surface mount)
90-position 0.05" spacing
(low cost)
Audio (J4 and J5)
Part Description
2x2 RCA jacks (
J4
3x2 RCA jacks (
J5
Two channel RCA interconnect
cable
ADSP-BF561 EZ-KIT Lite Evaluation System Manual
ADSP-BF561 EZ-KIT Lite Hardware Reference
2-8. For the availability and pricing of the
Manufacturer
SAMTEC
Mating Connector
SAMTEC
SAMTEC
SAMTEC
Manufacturer
)
SWITCHCRAFT
)
SWITCHCRAFT
Mating Connector
MONSTER CABLE
"Expansion
,
, and
J1
J2
Part Number
SFC-145-T2-F-D-A
TFM-145-x1 series
TFM-145-x2 series
TFC-145 series
Part Number
PJRAS2X2S01X
PJRAS3X2S01X
BI100-1M
2-19
