Expansion Interface Connectors (J1–3)
Three board-to-board connectors (
eral interfaces of the processor. The connectors are located at the bottom
of the board. For more information about the expansion interface, see
"Expansion Interface" on page
pricing, contact Samtec.
Part Description
90-position 0.05" spacing, SMT
90-position 0.05" spacing
(through hole)
90-position 0.05" spacing
(surface mount)
90-position 0.05" spacing
(low cost)

Audio In RCA Connector (J10)

Part Description
Two-channel right angle RCA jack
Two-channel RCA interconnect
cable
ADSP-21371 EZ-KIT Lite Evaluation System Manual
ADSP-21371 EZ-KIT Lite Hardware Reference
) provide signals for most periph-
J1—3
2-7. For the connector availability and
Manufacturer
SAMTEC
Mating Connectors
SAMTEC
SAMTEC
SAMTEC
Manufacturer
SWITCHCRAFT
Mating Cable
MONSTER CABLE
Part Number
SFC-145-T2-F-D-A
TFM-145-x1 series
TFM-145-x2 series
TFC-145 series
Part Number
PJRAS1X2S02
BI100-1M
2-21
