A B B M E A S U R E M E N T & A N A LY T I C S | O P E R AT I N G I N S T R U C T I O N
JDF300
Field indicator with
FOUNDATION Fieldbus communication
Introduction
—
JDF300 field indicator
The present manual provides information on
installing, operating, troubleshooting the field
indicator JDF300. Every section of the present
manual is specifically dedicated to the specific
phase of the field indicator lifecycle starting from
its receipt and identification, passing to the
installation, to the electrical connections, to the
configuration and to the troubleshooting and
maintenance operations.
The present manual can be used for JDF300 field
indicator.
The new JDF300 Foundation Fieldbus indicator
provides remote visibility for up to 8 variables,
subscribed from the bus (publisher/subscriber) or
directly written by the Host (client/server).
Each individual variable/input to be displayed can
be remotely selected through FF protocol or locally
selected operating on the housing push button or
through the local display menu: such delocalized
configuration capabilities saves time and greatly
improve productivity.
In addition to its standard function of Field
The field indicator JDF300 provides
simple and low cost remote
indication of a process variable on
an easy to read LCD display.
Measurement made easy
Indicator, the JDF300 is a Link Master device and
offers a set of Control Function Blocks improving its
calculation capability available for distributed
control strategy solutions.
For more information
Further publications for JDF300 are available
for free download from:
www.abb.com/measurement
or by scanning this code:
JDF300 field indicator –
Datasheet
JDF300 field indicator –
Operating Instruction
Search for or click on:
DS/JDF300-EN
OI/JDF300-EN
