Functional Principle, Technical Data
3.2

Technical Data

3.2.1

surfaceCONTROL 2500

Model
Measurement area
x-/y-axis
(Length / width)
Measuring range
z-axis
(Height)
Interfaces
Light source
Pattern frequency
Protection class
Temperature range
Dimensions
Sensor weight
Power supply
surfaceCONTROL 2500
surfaceCONTROL 2500
Measurement area (close) 260 x 190 mm
Measurement area (center) 300 x 220 mm
Measurement area (far) 340 x 250 mm
Resolution
Start of measuring range
Midrange
End of measuring range
Measuring range height
Gigabit Ethernet
USB 2.0
/BL
/GR
/RD
Sequence (typ.)
Sensor
Operation
Storage
Without cable
360 500
350 x 260 mm
2
400 x 300 mm
2
450 x 340 mm
2
≥ 0.25 mm ≥ 0.3 mm
475 mm 660 mm
550 mm 760 mm
625 mm 860 mm
150 mm 200 mm
Image data output
Sensor control
LED, 462 nm (blue)
LED, 528 nm (green)
LED, 612 nm (red)
up to 2 Hz
IP40
+5 ... +40 °C
-10 ... +50 °C, non-condensing
626 x 290 x 144 mm
7.0 kg
18 - 24 VDC, max. 150 W
720
500 x 375 mm
2 2
575 x 435 mm
2 2
650 x 495 mm
2 2
≥ 0.5 mm
950 mm
1100 mm
1250 mm
300 mm
3
