Functional Principle, Technical Data
3.2.2

surfaceCONTROL 2500/ST

Model
Measurement area
x-/y-axis
Measurement area (center)
(Length / width)
Measuring range
z-axis
(Height)
Interfaces
Light source
Pattern frequency
Protection class
Temperature range
Dimensions
Sensor weight
Power supply
3.3

LED Indicators

Each of the two cameras has two LEDs for status display on the rear side.
1 2
1 LED 1 Orange
Flashing orange
2 LED 2 Green
Flashing green
4 x fast flashing
Fig. 4 Table of LED indicators
surfaceCONTROL 2500
surfaceCONTROL 2500
Measurement area (close)
Measurement area (far)
Resolution
Start of measuring range
Midrange
End of measuring range
Measuring range height
Gigabit Ethernet LWL
USB 2.0 LWL
/BL
/GR
/RD
Sequence (typ.)
Sensor
Operation
Storage
W+without cable
Ethernet connection available
Ethernet data traffic
Power supply to the camera
Boot process is running
Transmission error
360-ST 500-ST
260 x 190 mm 350 x 260 mm
2
300 x 220 mm 400 x 300 mm
2
340 x 250 mm 450 x 340 mm
2
≥ 0.25 mm ≥ 0.3 mm
450 mm 620 mm
525 mm 720 mm
600 mm 820 mm
150 mm 200 mm
Image data output
Sensor control
LED, 462 nm (blue)
LED, 528 nm (green)
LED, 612 nm (red)
up to 2 Hz
IP40
0 ... +40 °C (+32 ... +104 °F)
-10 ... +50 °C (+10 ... +122 °F), non-condensing
626 x 290 x 144 mm
7.5 kg
18 - 24 VDC, max. 150 W
720-ST
500 x 375 mm
2 2
575 x 435 mm
2 2
650 x 495 mm
2 2
≥ 0.5 mm
850 mm
1000 mm
1150 mm
300 mm
3
