Mounting

Electrical mounting

Level transmitter

The Shuttle must not be connected to
®
the power supply before the ultrasonic
sensor is mounted and connected cor-
rectly.
When the cover has been removed, the
green plastic film with the menu symbols is
tipped up to gain access to the terminals.
can be supplied with 10 - 30 V DC
Shuttle
®
on terminal 10 and 12 or with 230 / 115 V
AC on terminal L and N.
Current regulations for conductor and
fuse dimensions should always be ob-
served.
Always confirm that the Shuttle
rating match the present voltage.
If Shuttle is delivered for 115 V AC supply,
®
it will be indicated with a label below the
leftmost terminal block as shown here:
Shuttle is intended
®
for 230 V AC.
EN 2.10 Shuttle Manual 1712
Mount the wires according to the terminal
numbers on the reverse side of the green
plastic film:
Terminal: Designation:
1 - 5
6 - 7
8 - 9
10 and 11 4-20 mA output
10 and 12 10 - 30 V DC supply
voltage
®
Shuttle is intended
®
for 115 V AC.
9
Ultrasonic sensor
Relay output 1
(Max. 50 V, 1 A resistive load)
Relay output 2
(Max. 50 V, 1 A resistive load)
(Max. 500 Ω load)
L 230 / 115 V AC live
N 230 / 115 V AC neutral
