Quick Installation Guide - FM-approved MJK Ultrasonic Sensors
MJK Ultrasonic Sensor Installation
MJK Automation A/S offers a variety of FM-approved ultrasonic sensors for the MJK Shuttle
MJK 704 Pump Controller and the MJK 713 Open Channel Flow Converter.
This quick guide solely covers mounting and installation of the FM-approved MJK Shuttle sensors in hazardous
locations.
• Shuttle Ultrasonic Sensor Type 200630 - Extended Range w/ 39 ft. cable
®
• Shuttle Ultrasonic Sensor Type 200631 - Extended Range w/ 150 ft. cable
®
Shuttle
Range:
Frequency:
Spread:
Deadband:
Temperature:
Materials:
• Shuttle Ultrasonic Sensor Type 200640 - Standard Range w/ 39 ft. cable
®
• Shuttle Ultrasonic Sensor Type 200641 - Standard Range w/ 150 ft. cable
®
Shuttle
Range:
Frequency:
Spread:
Deadband:
Temperature:
Materials:
• Shuttle Ultrasonic Sensor Type 200650 - Short Range w/ 39 ft. cable
®
• Shuttle Ultrasonic Sensor Type 200651 - Short Range w/ 150 ft. cable
®
Shuttle
Range:
Frequency:
Spread:
Deadband:
Temperature:
Materials:
See comprehensive information about the MJK Shuttle
MJK 713 Open Channel Flow Converter in their respective data sheets, installation and user manuals.
Sensor Installation in Class I, II and III, Div. 1 & 2, A, B, C, D, E, F, G Hazardous Locations
UltraSonic Sensor Installation DWG 5049 070327
EN 2.10 Shuttle Manual 1712
® Ultrasonic Sensor: 200630 (200631)
75 ft. (fluids), 30 ft. (solids)
30 kHz
6°
32"
- 5 °F to + 150 °F
PBF/ceramic
Ultrasonic Sensor: 200640 (200641)
®
35 ft. (fluids), 15 ft. (solids)
40 kHz
7°
14"
- 5 °F to + 150 °F
PBF/ceramic
® Ultrasonic Sensor: 200650 (200651)
10 ft. (fluids), 4 ft. (solids)
75 kHz
7°
14"
- 5 °F to + 150 °F
PBF/ceramic
® Level Converter, the MJK 704 Pump Controller and the
Page 1 of 2
35
® Level Converter, the
90
-40
-30
60
-20
-10
dB
30 30
0
90
-40
-30
60
-20
-10dB
30 30
0
90
-40
-30
60
-20
-10dB
30 30
0
MJK North America, Inc.
37 Sherwood Terrace, #126
Lake Bluff, IL 60044
Tel: 847-482-8655
877 MJK LINK
Fax: 847-482-8654
mjkusa@mjk.com
www.mjk.com
SW 838023
