Summary of Contents for Xylem FLYGT LTU601
- Page 1 Installation and Operation Manual LTU601...
-
Page 3: Table Of Contents
Table of Contents Table of Contents 1 Introduction and Safety......................2 1.1 Introduction.......................... 2 1.2 Safety terminology and symbols..................2 1.3 User safety..........................3 1.4 Disposal of packaging and product.................. 3 1.5 Spare parts..........................3 1.6 Warranty..........................4 1.7 Support..........................4 2 Product Description........................5 2.1 General description......................5 2.2 Approvals and standards.................... -
Page 4: Introduction And Safety
This includes any modification to the equipment or use of parts not provided by Xylem. If there is a question regarding the intended use of the equipment, please contact a Xylem representative before proceeding. -
Page 5: User Safety
Risk of electrical shock or burn. A certified electrician must supervise all electrical work. Comply with all local codes and regulations. All work on the product must be carried out by certified electricians or Xylem authorized mechanics. Xylem disclaims all responsibility for work done by untrained, unauthorized personnel. -
Page 6: Warranty
1 Introduction and Safety 1.6 Warranty For information about warranty, see the sales contract. 1.7 Support Xylem only supports products that have been tested and approved. Xylem does not support unapproved equipment. LTU601 Installation and Operation Manual... -
Page 7: Product Description
2 Product Description 2 Product Description 2.1 General description The package The package includes: • Level transmitter unit sensor • Cable holder About the level sensor The level sensor is designed for submerged measuring of liquid levels in open channels, drains, or tanks. - Page 8 2 Product Description Sensor body dimensions mm (6.57 in) mm (2.36 in) Cable fitting dimensions 236 mm (9.29 in) 60 mm (2.36 in) The image shows the dedicated cable fitting for the free-hanging sensor unit. LTU601 Installation and Operation Manual...
-
Page 9: Mechanical Installation
3 Mechanical Installation 3 Mechanical Installation Precautions Before starting work, make sure that the safety instructions in the chapter Introduction and Safety (page 2) have been read and understood. 3.1 Mounting configuration The level sensor is submersible. • When it hangs free from the cable with dedicated suspension attachment, it is not position-dependent. -
Page 10: Electrical Installation
4 Electrical Installation 4 Electrical Installation Precautions Before starting work, make sure that the safety instructions in the chapter Introduction and Safety (page 2) have been read and understood. DANGER: Electrical Hazard Before starting work on the unit, make sure that the unit and the control panel are isolated from the power supply and cannot be energized. -
Page 11: Technical Reference
5 Technical Reference 5 Technical Reference 5.1 Technical data Electrical specifications Feature Description Measuring principle Piezoresistive Supply voltage 10–30 V DC Output signal 2–wire 4–20 mA, passive transmitter Linearity / Stability Better than ± 0.5% FS / ± 0.1% FS Measurement accuracy Better than ±... - Page 12 5 Technical Reference • Minimum programmable range 0–2 m (0–6.56 ft) • Maximum programmable range 0–12 m (0–39.37 ft) • Maximum overpressure 3 bar Optional part numbers Part number Option 834526 Copper ring Unique part number per order Non-standard cable lengths Unique part number per order Non-standard measuring range Accessories and spare parts...
- Page 16 For more information on how Xylem can help you, go to xyleminc.com Refer to www.xylemwatersolutions.com/contacts/ for contact details of your local sales and service representative.
