Display and keyboard
Units of measurement
If the measuring unit is changed, all other values in menus
and settings will automatically be converted to the new
measuring unit.
In this example the measuring unit is changed from metres
to feet.
The settings will be rounded off automatically.
Select unit with the arrow keys.
The dot indicates the position of the decimal separator.
2,00 m
0,00 m
Note:
'mm' or 'in' cannot be selected if it could cause
overrun in the display read-out.
Shuttle
reverts to normal read-out with the new measuring
®
unit.
EN 2.10 Shuttle Manual 1712
6,59 ft
0,0 ft
17
SW 838023
