Introduction

Safety instructions

1: Read this manual carefully.
2: Be aware of the environment at the in-
stallation site. Wear necessary protective
equipment and follow all current safety
regulations.
3: Shuttle can provide a start signal for
®
dangerous machinery. Always ensure
that connected machinery and other
equipment are effectively being put
out of service (i.e. removal of main
fuses, lock main- and/or security
switches in off position) before com-
mencing setting, fault finding, service
and maintenance work etc.
4: There is a risk of lethal electrical shock
from terminal 1 to 5 and L-N. Be careful
not to touch these while Shuttle
service.

Repair

1: Repair of Ex approved equipment (ul-
trasonic transmitter) must only be made
by MJK or by a service representative
approved by MJK.

Ex equipment

1: All current local and national standards,
regulations regarding installation and use
of Ex approved equipment, certifications
and safety instructions for Ex equipment,
that have been used together with the
installation of Shuttle
®
observed.
EN 2.10 Shuttle Manual 1712

Product identification

Check that the item(s) delivered corre-
sponds to the ordered item(s). The item
number is printed on a label that is sticked
onto the packing. Shown below is the label
for a delivery including a level transmitter
and a ultrasonic sensor:
is in
®
➀
➁
➀
➁
➀
➁
An identical marking can be found on the
right hand side of the level transmitter
must be strictly
cabinet:
6
➂
Item number Serial number
Item description
➂
➂
SW 838023
