57" Flush Mount Direct Drive Endura® Fan
Spacing
Planning the layout of the spacing between fans is very important. Spacing too close together will cause
interference between the discharge cones.
Installation
Inspecting the Shroud
Inspect the Shroud assembly for hardware as received.
(53626) Center V-Post
MV2494A
72" [182.9cm]
Recommended Spacing
5" [12.7cm]
60-1/16"
[152.5cm] Mini-
mum Spacing if
sides of Cone are
flattened
(53026) Magnet Side Plate
Installation
(48427) Magnet
7
