57" Flush Mount Direct Drive Endura® Fan

Installing the Orifice Frame

Rounded Tab on the Cone

Cone Installation

Important! Before installing a Cone on assembled fan models do either A or B below.
A: Remove the Doors (Below): To remove the Doors Pull
near the center of the Door to allow the Door Pins to slide
out of the top Door Pivot Bracket. Once the Door is clear of
MV2494A
Important! Line up the Seam in the Orifice Frame
with one of the rounded Tabs on the Cone.
(53416)
Orifice
Frame
(46764) 5/16 Flg. Nut
the Top Pivot Bracket lift it
from the Bottom Pivot Plate
and set aside somewhere safe
to be reinstalled later.
Orifice Frame Shown Gray for Clarity.
(54287)
(54287) 5/16-18 x 1.00
B: Clamp the Doors (Below)
Clamp
Installation
(46764)
(53611)
Frame
Bracket
SS Shldr. Bolt
13
