Chore-Time Endura Installation And Operator's Manual page 23
57" flush mount direct drive fan
Hide thumbs
Also See for Endura:
- Instruction manual (35 pages) ,
- Installation & operator's instruction manual (35 pages)
Table of Contents
Advertisement
Item
Qty.
1
1
Motor, 230V, 7A, 630RPM PMSM
Motor, 380-480V, 4.1A, 630RPM PMSM
2*
1
57" Fan Shroud Assembly
4*
2
57" Cross Rod Coupler
6*
2
Rivet
7*
1
57" Fan Center Post Stiffener
8*
1
57" Fan Cross Rod
9*
8
Magnet Side Plate
10*
4
.125 x 50 Magnet
12*
1
Fan Danger Decal
13
4
57" DD Fan Motor Support
14
1
57" Galv. Bolted Hub Blade
57" SS Blade
15
2
Upper Corner 57" DD Fan Support (2 Notches)
16
2
Lower Corner 57" DD Fan Support (1 Notch)
17
4
Cone Bracket
24
4
5/16-18 x 1.25 HH 316SS Bolt
27
1
59" Square 1.25 x 2 Wire Screen
28
47
5/16-18 x Hx. Serrated SS Flange Nut
29
8
5/16-18 x 3/4 HH SS Bolt
31
12
1/4-10 x 1.5 HXWH SS Lag Screw
32
1
57" DD Endura Fan Decal
36
8
Screen Clip
46***
20
1/4-20 x 7/8 SS Bolt
47***
20
1/4-20 SS Serrated Flange Nut
48***
8
1/4-20 x 1/2 SS Screw
50
1
57" DD Flush Mount Bottom Panel (2 Notches)
51
1
57" DD Flush Mount (Right) Side Panel (1 Notch)
52
1
57" DD Flush Mount (Left) Side Panel (4 Notches)
53
1
57" DD Flush Mount Top Panel (3 Notches)
* Fan Shroud Assembly (Item 2) includes items 4,6,7,8,9,10, & 12
***Included in Flush Mount Hardware Package (pn 56978)
Description
Part No.
57" Direct Drive Endura
56501
56704
52925
56339
48936
53626
53398
53026
48427
2527-90
56502
56494
54530
56592
56593
53039
4412-28
56540
46764
4412-11
41561
39002-XXX
56671
4404-17
46298
54683
56973
56971-2
56971-1
56972
®
Fan (56911-X,-XS) Part Numbers
-1,-2,-1S,-2S
-3,-3S
All
All
All
All
All
All
All
All
All
-1,-2,-3
-1S,-2S,-3S
All
All
All
All
All
All
All
All
All
All
All
All
All
All
All
All
All
