RECOMMENDED CONFIGURATION
Lian Li DK 05F – Left
RETURN FROM RADIATOR 2
Radiator 1: Up to XE 360mm
OUTLET TO GPU
Radiator 2: Mandatory PE 480mm
RETURN FROM GPU
OUTLET TO UNI 140
INLET FROM UNI 140
OUTLET TO RADIATOR 1
RETURN FROM RADIATOR 1
OUTLET TO RADIATOR 2
Lian Li DK 05F – Right
RETURN FROM RADIATOR 1
Radiator 1: Up to XE 360mm
Radiator 2: Mandatory PE 480mm
OUTLET TO GPU
RETURN FROM GPU
OUTLET TO UNI 140
INLET FROM UNI 140
OUTLET TO RADIATOR 2
RETURN FROM RADIATOR 2
OUTLET TO RADIATOR 1
- 9 -
