INSTALLING WATER COOLING COMPONENTS
360mm RADIATOR/
FAN BRACKETS
To install the radiators, all of the fan mounting brackets must be
removed.
480mm
RADIATOR/FAN
STEP 1
BRACKETS
Remove the 360mm and 480mm bracket from the left or right side
of the desk - depending on what corresponds to your EK-Quantum
Reflection DK-05F product. There are two (2) thumb screws and two
(2) locating screws per bracket.
STEP 1
- 4 -
