4.2.23.4 Electrical limit values of the RE multiplier
V Supply voltage of the RE multiplier
in
I max. power consumption of the RE
in max.
I
out max.
I
in max.
f
max.
t / t
r f
4.2.23.5 Function of the RE multiplier
The RE multiplier contains an own driver / amplifier for each connection. All signals are buffered (A,
B, N, A inverted, B inverted and N inverted). This enables the application of systems that require all
signals of an encoder. The RE multiplier is not galvanically isolated.
Due to the identical structure of the driver, there is no temporal delay between the individual signals
at the four outputs.
4.2.23.6 RE extension cable
The RE extension cables offered by REA JET can be used to connect the RE multiplier and the
control devices. The cables are offered in various length and two models.
Figure 210: Scope of delivery of the RE extension cable
Instruction manual
REA JET HR pro 2K / 4K
V 3.5x_001 28.05.2015
Name / Function
multiplier
max. load current per channel (for
each of the four RE ouputs)
max. load of the RE per channel
Phase shift
Pulse-pause ratio
Max. pulse frequency
edge steepness
Table 43: Electrical limit values of the REA JET RE multiplier
Page 150 / 189
Value
10 - 30
800
60
4
like the
input
like the
input
200
< 1
Name
Encoder, extension cable, L=1m
Encoder, extension cable, L=2m
Encoder, extension cable, L=5m
Encoder, extension cable, L=10m
Encoder, extension cable, L=20m
Unit Tolerance
V DC
mA
mA
mA
kHz
µs
Article
number
054.853.010
054.853.020
054.853.050
054.853.100
054.853.200
