REA JET HR pro 2K User Manual page 125

4.2.18.1 Print head connection
4.2.18.1.1 Assignment of the print head connection
Pin HR Name
A Internal ground
B
1RIN+
C 1RIN-
D 1DO+
E 1DO-
F Internal ground
G Head_30V
H Head_30V
J NC
K Head_24V
L Internal ground
M Internal ground
*) = 2x 2x AWG24 (CAT6)
Table 25: Assignment of the print head connection (A4, A9, A15, A16)
4.2.18.1.2 The REA JET print head cable
The data connection between the REA JET HR pro 2K/4K control device and the print heads is a
high-speed communication interface. The requirements with regard to cable quality and transfer are
comparable to those of a CAT 6 network cable. With the application of LVDS technology, this
connection is particularly resistant against external influences. The REA JET print head cable has
been specially developed for these requirements and is drag-chain compatible.
Name / Requirement
cable diameter approx.
min. bending radius
Drag chain movement cycles
Instruction manual
REA JET HR pro 2K / 4K
V 3.5x_001 28.05.2015
Function
Mass
Logic + product sensor
LVDS in
LVDS in
LVDS out
LVDS out
Mass
Pen Driver Board
Supply voltage
Pen Driver Board
Supply voltage
Pen Driver Board
NC
Supply voltage
Logic + product sensor
Mass logic
NC
**) = 3 x AWG 24
Table 26: Mechanical limit values of the REA JET print head cable
Due to the high data transfer rate and the importance of print
head cables, REA JET urgently recommends using only
genuine REA JET print head cables.
Page 125 / 189
Value Wire color
Mass rs
0.5V
ws/or
0.5V or
0.5V ws/gn
0.5V gn
Mass gn
30V DC ws
30V DC bn
NC
24V DC ge
Mass gr
NC
***) = 3 x AWG 24
Value static Value dynamic
8
24
3,000,000
I I/O Pin SK
*** A
C
*
* B
* E
* D
** F
** G
** H
Y
*** K
*** L
M
Unit
8 mm
80 mm
cycles
