Ordering information

To order the Nucleo-64-P board corresponding to the targeted STM32, refer to
Order code
NUCLEO-L412RB-P
NUCLEO-L433RC-P
NUCLEO-L452RE-P
The meaning of the codification is explained in
NUCLEO-LxxxRy-P
Lxxx
R
y
-P
This order code is mentioned on a sticker placed on bottom side of the board.

Conventions

Table 3 provides the conventions used for the ON and OFF settings in the present
document.
Convention
Jumper JPx ON
Jumper JPx OFF
Jumper JPx [1-2]
Solder bridge SBx ON
Solder bridge SBx OFF
In this document the references for all information that is common to all sale types, are
"STM32 Nucleo-64-P board" and "STM32 Nucleo-64-P boards".

Table 1. Ordering information

Table 2.

Table 2. Codification explanation

Description
STM32 Product line
STM32 package pin count
STM32 Flash memory size (8 for 64
Kbytes, B for 128 Kbytes, C for 256
Kbytes, E for 512 Kbytes, G for
1MKbyte, H for 1.5 Mbytes and I for
2 Mbytes)
External SMPS architecture.

Table 3. ON/OFF convention

Jumper not fitted
Jumper should be fitted between Pin 1 and Pin 2
SBx connections closed by 0 ohm resistor
SBx connections left open
UM2206 Rev 3
Ordering information
Table
Target STM32
STM32L412RBT6P
STM32L433RCT6P
STM32L452RET6P
Example: NUCLEO-L452RE-P
STM32L452
64 pins
E = 512 Kbytes
Definition
Jumper fitted
1.
