NUCLEO-L412RB-P, NUCLEO-L433RC-P and NUCLEO-L452RE-P I/O assignment
Table 16. NUCLEO-L412RB-P, NUCLEO-L433RC-P and NUCLEO-L452RE-P
Pin
Pin name
No.
31 V
SS
32 V
DD
33 PB12
34 PB13
35 PB14
36 PB15
37 PC6
38 PC7
39 PC8
40 PC9
41 PA8
42 PA9
43 PA10
44 PA11
45 PA12
46 PA13
47 V
SSUSB
48 V
DDUSB
49 PA14
50 PA15
51 PC10
52 PC11
53 PC12
54 PB3
55 PB4
56 PB5
57 PB6
58 PB7
59 PH3-BOOT0
60 PB8
61 PB9
62 V
DD1V2
I/O assignment (continued)
Signal or label Main feature / optional feature (SB)
GND PWR GND
V PWR V
DD_MCU
PB12 I/O
PB13 ARD_D13 - SPI2_SCK / LED / IO
PB14 ARD_D12 - SPI2_MISO / IO
ARD_D11 - SPI2_MOSI - TIM15_CH2 /
PB15
I/O
PC6 I/O
PC7 ARD_D7 / IO
PC8 I/O
PC9 I/O
PA8 ARD_D9 -TIM1_CH1 / IO
UART1_TX ARD_D1_TX / STLINK_TX
UART1_RX ARD_D0_RX / STLINK_RX
PA11 ARD_D10 -TIM1_CH4 - SPIx-CS / IO
PA12 ARD_D2 / IO
PA13 TMS_SWDIO
GND PWR GND
V / V PWR V
DD_MCU DD
PA14 TCK_SWCLK
PA15 ARD_D5 - TIM2_CH1 / IO
PC10 I/O
PC11 I/O
PC12 I/O
PB3 ARD_D3 - TIM2_CH2 / SWO
PB4 I/O
PB5 ARD_D4 / IT5
PB6 ARD_D8 / IO
PB7 ARD_D14 - I2C1_SDA / IO
BOOT0 BOOT0
PB8 ARD_D15 - I2C1_SCL / IO
PB9 I/O
V PWR ExtSMPS 1.1 V
DD12
UM2206 Rev 3
1.8 V / 3.3 V
DD_MCU
1.8 V / 3.3 V
DD_MCU
41/55
