The Toolbar

The Summary View

The Device View

The Toolbar is always displayed at the top of the browser window,
underneath the Banner. It contains three buttons which allow you to
select different views:
The Summary View
I
Click Summary to display the Summary View. This view allows you to
update the latest summary information for the Webcache.
The Device View
I
Click Device View to display the Device View. This view allows you to
configure the physical and networking aspects of the Webcache.
The Help View
I
Click Help to display the Help View. This view allows you to access the
Online Help system for the Webcache, additional information from the
3Com Web site and provides specification guidelines for running the
Web interface.
Click Summary on the Toolbar to access the Summary View. This is the
default view when you first browse to the Webcache and when you click
the browser Refresh button.
Click the System icon in the Navigation Tree to update the Information
Area with the latest summary information for the Webcache.
The summary information is displayed in a table:
Device Summary
I
The table is entitled System Summary and displays information for the
Webcache. It shows the System Name, Location, Contact, Up Time,
Type, Software Version, Hardware Version and IP Address of the
Webcache.
The Summary View only displays information for the Webcache. You
cannot perform any operations from this view. You must use the Device
View to perform operations.
Click Device View on the Toolbar to access the Device View. This view
allows you to configure the physical and networking aspects of the
Webcache.
The Toolbar 61
