40 C 2: I
HAPTER NSTALLING THE
Setting Up Using the
Command Line
Interface
Client Machine Client Machine
W
EBCACHE
Figure 14 User name and password screen
If the user name and password screen is not displayed, see "Solving Web
Interface Problems" on page 130.
4 Enter your user name and password. For further information, see
"Logging in as a Default User" on page 58. Click OK.
5 The Getting Started wizard is displayed when the Web interface has
loaded. You must configure the basic settings of the Webcache by
completing the Getting Started wizard before you introduce the
Webcache to your live network. For more information, see "Getting
Started Wizard Settings" on page 43.
You can setup the Webcache for management via the Command Line
Interface by running a Telnet session on a management workstation that
is connected to the Webcache over your test network, or locally via a
console port connection.
Setting Up Over the Test Network
The Webcache is pre-configured with a default IP address, which is within
the range of addresses reserved by the IETF for private IP networks. This
default address allows you to run the Command Line Interface without
any initial configuration of IP addresses. The default IP address of the
Webcache is 192.168.1.253.
Figure 15 Setting Up Over the Test Network
Switch/Hub
1 2 2 3 3
LAN LAN LAN WAN Activity Activity
Cache Storage Status Power/Self test
Link Status Cache Storage Status green = ok Webcache 3000
green = 100 Mbps
yellow = failed Link Status
yellow = 10 Mbps
3C16116
SuperStack 3 ®
Webcache
