Lan Problems With Odi Drivers - 3Com 3CCFEM556 User Manual

58 C
HAPTER

LAN Problems With ODI Drivers

Symptom
Unable to configure the adapter.
After running VLM.EXE, "File
Server Not Found".
Machine displays "Using DOS ver
x.xx" then hangs.
The LSL is not loaded.
A TSR is loaded above the driver.
The Adapter did not initialize.
An invalid keyword was specified
in NET.CFG on line x.
The Frame type specified in the
NET.CFG file is not supported.
Enabler cannot activate card
Enabler activates the card but it
cannot see the server.
Enabler fails to find the card
Problems connecting to the
server.
9: D
IAGNOSTICS AND
Solution
T
ROUBLESHOOTING
Card is not installed or is in the wrong slot.
Otherwise, it is not being recognized by C&SS
or the enabler, or the enabler is not loaded.
Make sure the Ethernet frame type in
NET.CFG is the same as in your network.
Try a different interrupt (IRQ) in the range of
3, 4, 5, 7 (sometimes), 9, 1, 11, 12, or 15.
The LSL must be loaded in order for
FEM556OD.COM (ODI) to work.
A Terminate-and-Stay-Resident file was
loaded after FEM556OD.COM.
An expected resource is not, such as an I/O
window at the PORT address in NET.CFG.
NET.CFG contains parameter entries known
as Keywords, one of which was not
recognized. Check Keywords in NET.CFG.
Legal frame types:
802.3,
FRAME ETHERNET_
FRAME ETHERNET_SNAP.
Try to make more resources available (BIOS)
Try to force Enabler to use a different IRQ
(possibly found by CONFIG), for example:
FMENABLE IRQ=A
Where A is the hexadecimal value of 10.
Verify the EMM386.EXE exclusion setting in
CONFIG.SYS.
Make sure CONFIG.SYS supports enough
logical drives for the network. Add the line
LASTDRIVE=Z
to CONFIG.SYS.
Check the NET.CFG settings.
802.2,
FRAME ETHERNET_
FRAME ETHERNET_
II,
