Inserting the LAN+Modem Card

7
When attaching connectors to the LAN+Modem card,
insert them with the icon side up. Be sure to attach the
connector to the correct port. You cannot damage the card
using the wrong port, but it will not operate if the cables
are mismatched.
Inserting the LAN+Modem Card
These general instructions apply to most notebook
computers. Refer to the manual that accompanied your
computer for instructions specific to your computer.
To install the card, slide it into the PC Card slot, as shown in
Figure 2-2. The power to the computer can be on or off.
Without forcing the card, push until it seats firmly.
Figure 3 Inserting the LAN+Modem Card
CAUTION: Forcing the card into the slot may bend the pins
inside the slot. If you don't know how to insert cards in
your computer, refer to the documentation supplied with
your computer on using PC Card (PCMCIA) slots.
Do not pull the cable to disconnect the connector from the
card. This may damage the card and make it inoperable.
Refer to the section "Disconnecting and Removing the
LAN+Modem Card" on page 10 of this chapter.
