8.5

MODBUS TCP

8.5.1

Settings

To change the Modbus TCP Settings you need to be logged in as
Select MODBUS TCP
Parameter
Obtain IP settings
from a DHCP server
IP Address
Subnet Mask
Default Gateway
Default TCP Port
Additional TCP Port
Watchdog [msec]
Apply
Version EN-092019-1.21
Settings and follow the instructions in the section
Meaning
If the checkbox is selected, the IP settings for MODBUS TCP access are
obtained from DHCP server. IP Address, Subnet Mask and Default Gateway
cannot be configured.
IP address for MODBUS TCP access.
Subnet mask
Default gateway
Default TCP port
If defined, this port can also be used for Modbus communication.
See Section Connection Monitoring
Click button to activate your settings.
Chapter 8 - Using the web interface
51
administrator .
Configuring Modbus
37
.
27
.
61
