Unpacking BenchCel Microplate Handler

Unpacking BenchCel Microplate Handler
About this topic
Shipping containers
Before you start
WAR NING
42
This topic describes how to unpack the BenchCel Microplate Handler from the shipping
containers.
The shipping containers include:
•
BenchCel crate containing the BenchCel device.
•
Peripherals box containing the following packages:
–
BenchCel utility kit
–
Pendant
–
BenchCel robot head
–
Safety shield with hardware
–
Labware racks
•
Computer box
Depending on the configuration ordered, additional packages or items can be included.
Verify the following:
1
BenchCel utility kit contents. At a minimum, the kit contains the following:
•
Power cord
•
Serial and Ethernet cables, and Ethernet switch
•
Tubing for air line
•
Software CD-ROM
2
Site specifications. Ensure the installation site meets the requirements. See
"Verifying laboratory requirements" on page
Note the dimensions of the shipping container before moving it to make sure you
have adequate clearance through doorways and passages.
3
Tools and equipment requirements. Obtain the following:
•
Large screwdriver to open the shipping crate
•
Hex wrenches: 5-mm and 2-mm for mounting the robot head
•
Cart for moving the BenchCel device
4
Personnel requirements. Make sure two people are available to lift the BenchCel
device from the crate.
The BenchCel device without labware racks weighs 28 – 51 kg (61.7 – 112.4 lb),
depending on the configuration. Attempting to lift or move the BenchCel device
without assistance could cause personal injury. Request assistance and use proper
lifting techniques when lifting or moving the device.
