Configuring the ISDN
LAN Modem from a
Remote Location
You may need to scroll down to see the Lock Configuration section. A message
indicates that the configuration is locked.
To unlock the configuration, do the following.
1 Click Continue.
The Enter Password window appears.
2 Enter your password to access the ISDN LAN Modem configuration program.
3 Click Submit. The ISDN LAN Modem main configuration page appears.
To access and make configuration changes to your ISDN LAN Modem remotely,
you will need an ISDN modem, a Web browser, and any PPP dialer software, such
as Windows 98/95's Dial-Up Networking, installed on your local computer.
An example using Windows 98/95 Dial-Up Networking follows.
1 Click Start, Programs, Accessories, (Windows 98 users select Communications)
and select Dial-Up Networking.
2 Double-click Make New Connection.
The Make New Connection window opens.
3 Enter a name to designate this dial-up profile, such as LAN Modem.
4 Select the ISDN modem attached to your local PC from the drop down list box and
click Next.
The Make New Connection phone number window will open.
5 Enter the phone number of the remote ISDN LAN Modem to which you wish to
connect and click Next.
6 Click Finish to complete the Make New Connection setup.
You will now have a new icon for the connection just created.
7 Right click this new icon with your right mouse button and choose Properties.
8 Click the Server Type tab.
For Windows 95 users: PPP, Windows 95, Windows NT 3.5, Internet should be
chosen in the Type of Dial-Up Server list box.
For Windows 98 users: PPP, Internet, Windows NT Server, Windows 98, should be
chosen in the Type of Dial-Up Server list box.
9 Under Advanced Options, uncheck all boxes.
10 Choose the TCP/IP check box for Allowed Network Protocols. Uncheck the boxes
for NetBEUI and IPX/SPX Compatible.
11 Click TCP/IP Settings.
The TCP/IP Settings window opens.
12 Click Specify an IP address and enter an IP address for your computer. Enter
192.168.2.1 if you are not sure.
13 Leave the other options for this window at their default settings, including the
radio button for Server assigned name server addresses.
14 Click OK to close the TCP/IP Settings window.
Configuring the ISDN LAN Modem from a Remote Location
79
