Configuring A Static Ip Address On The Isdn Lan Modem - 3Com OfficeConnect 3C892A User Manual

Configuring a Static IP
Address on the ISDN
LAN Modem
15 Specify the B channel rate.
Leave the B channel rate set to 64 Kbps unless your telephone company and the
locations to which you will be connecting only support 56 Kbps.
16 Click Continue.
A call is launched to your ISP. A congratulations message appears when you
successfully connect to your ISP. This verifies the correct configuration of your ISDN
line and ISP connection.
This configuration covers the typical parameters needed to connect to your ISP.
There are additional parameters for this ISP connection which have been set to a
typical default. These parameters include Domain Name, Compression, NAT, and
WAN Link IP Address. In addition, you can enter a second telephone for
connection to your ISP. For information on these parameters and instructions for
changing their default values, refer to
17 Click Continue to connect to the ISDN LAN Modem Web site where you should
register the product and view the ReadMe file which contains the latest
information.
Bookmark this URL for all the latest, up to date information about your ISDN LAN
Modem (
http://www.remoteaccess.3com.com/support/docs/lanmodem
If you cannot access a Web site and your computer has a static IP address, refer to
"Configuring a Static IP Address on the ISDN LAN
other problems, refer to Chapter 9, "Troubleshooting and Maintenance."To return
to the LAN Modem's main configuration page, click Configure Modem from the
Web page.
If you followed the steps in
Configuration" and were not able to connect to a Web site and your computer
has a static IP address, there may be an incompatibility between the IP address on
your computer and the IP address on the ISDN LAN Modem. To correct this, do the
following.
1 Enter the following URL in your Web browser:
2 From the ISDN LAN Modem's main configuration page click on the ISDN LAN
Modem icon in the illustration.
The LAN (Ethernet) Parameters page appears.
3 In the IP Address field, enter the default gateway address you entered as described
in "Setting Up Your Computer If You Have a Static IP
4 Click Submit.
The ISDN LAN Modem will reset.
5 Click Refresh from your Web browser's menu bar.
The Enter Password window appears.
6 Enter your password and then click Submit.
The ISDN LAN Modem's main configuration page appears.
7 Click the ISP Wizard button.
You will see the information you entered previously.
8 Click Continue.
"Editing Service Provider
Modem." If you experience any
"Configuring the ISDN LAN Modem for the Typical
http://3Com.OC.lanmodem/mainpage
Before You Begin
Profiles."
).
Address".
55
