Links from the
Illustration

Links from the Buttons

By clicking on the icons in the illustration, you can jump to the following locations.
Service Providers: Jumps to the Service Providers page where you can
configure a connection to an ISP or a private network.
Workstations: Jumps to the Workstation Selection page where you can view a
workstation's IP address and can change its associations with service providers.
ISDN Parameters: Jumps to the ISDN Parameters page where you can
manually configure ISDN parameters.
LAN Parameters: Jumps to the LAN Parameters page where you can configure
Ethernet parameters for the ISDN LAN Modem.
Data Call Parameters: Jumps to the Data Call Timeout Parameters page.
From here you may set inactivity timers, which allow calls to be disconnected
due to network inactivity, keeping telephone usage and Internet access costs
down.
Call Routing: Jumps to the Call Routing page where you can configure how
you would like data and voice calls routed.
Current Call Status: Jumps to the Call Statistics page where the latest call
information is displayed.
Home: Jumps to the main configuration page of the ISDN LAN Modem.
ISP Wizard: Allows you to configure an ISP. If you already configured an ISP
using the ISP Wizard, and then you run ISP Wizard again, the latest ISP will
overwrite the previous one. To add a second ISP, go to the Service Providers
page.
Manual Calling: Jumps to the Manual Calling page where you can connect
and disconnect calls.
Statistics: Jumps to the Statistics page where you can view statistics regarding
the following: system, ISDN, current call, last call and service provider.
Maintenance: Jumps to the Maintenance page where you can reset the ISDN
LAN Modem as well as place the ISDN LAN Modem in firmware download
mode in order to download the latest firmware.
Password: Jumps to the Password page restrict access to the LAN Modem
WebWizard by configuring a password.
Context-sensitive help is available in the bottom frame of each configuration
screen. To increase the size of the help frame, drag the pane separator up.
This chapter covers the typical configuration steps required for a basic
understanding of your ISDN LAN Modem functionality. For further configuration
options, refer to Chapter 6, "Advanced Configuration."
ISDN LAN Modem Main Page
