Tone Definitions
The following table lists the tone definitions for voice calls.
Table 19
Tone
Busy tone *
Call waiting tone
Configuration positive acknowledgment tone
Configuration negative acknowledgment tone
Call waiting and CLIR enabled confirmation
tone
Call Waiting and CLIR disabled confirmation
tone
ISDN Line Disconnected Tone
* Generated when the ISDN LAN modem does not have an available B channel to place an outgoing
voice call.
Tone Definitions
Cadence
0.4 on, 0.4 off (20 seconds)
0.2 on, 0.2 off;
0.2 on, 4.4 off (for 45 seconds)
0.3 on, 0.1 off;
0.3 on, 0.7 off (for 5 seconds)
0.1 on, 0.1 off;
0.1 on, 0.1 off;
0.1 on, 0.5 off (for 5 seconds)
0.3 on, 0.1 off;
0.3 on, 0.7 off (for 5 seconds)
0.1 on, 0.1 off;
0.1 on, 0.1 off;
0.1 on, 0.5 off (for 5 seconds)
0.1 on, 0.1 off (for 20 seconds)
115
