3Com OfficeConnect 3C892A User Manual page 44

C 4: S U
38
HAPTER ETTING P
TCP/IP W M
FOR INDOWS AND ACINTOSH
Figure 20 Select Network Component Type Dialog Box
3 Select Protocol and then click Add.
The Select Network Protocol dialog box appears.
Figure 21 Select Network Protocol Dialog Box
4 From the Manufacturers list box, select Microsoft, and then from the Network
Protocols list box, select TCP/IP.
5 Click OK.
6 Select the Configuration tab.
The Network Configuration dialog box appears.
7 Select TCP/IP and then click Properties.
If you have multiple TCP/IP entries, select TCP/IP for the Ethernet card associated
with the ISDN LAN Modem.
