3Com OfficeConnect 3C892A User Manual page 60

C 5: C
54
HAPTER ONFIGURING THE
ISDN LAN M
ODEM
Figure 39 ISP Wizard Window
If you do not want to use the ISP Wizard, click Abort. The ISDN LAN Modem
configuration main page appears. Refer to
Providers"for instructions on configuring your ISP connection manually.
10 In the Name field, enter the name of your ISP.
11 In the Telephone Number field, enter the telephone number of your ISP.
If the telephone number contains a subaddress, enter the telephone number,
followed by an asterisk (*) and then the subaddress number. For example, type
020 555 1212 *3.
If you want to enter another telephone number to connect to your ISP or change
these settings, refer to
completed this typical installation procedure.
12 In the User ID and Password fields, enter your user ID and password for your ISP
account.
13 If your ISP requires a DNS address, enter it in the DNS Address(es) field.
14 Specify how you want the bandwidth allocated for this connection.
Use one B channel: When selected, one B channel is used to connect to
this service provider.
Add second B channel as required: When selected, the second B channel
is added when the first B channel reaches a certain threshold. The threshold
default is 60%. To change the threshold default, refer to
Call Parameters" in Chapter 6. The second B channel is temporarily
removed when you place or answer another call.
Use two B channels: When selected, both B channels are used to connect
to this service provider (that is, always use Multilink PPP). Note that this
prevents another call, data or voice to be placed or received as there is no
available bandwidth (that is, the second B channel cannot be temporarily
removed).
"Setting Up Additional Service
"Editing Service Provider Profiles" after you have
"Changing Data
