Using Rubber Feet and Stacking Clips

Attach the feet to the marked areas at each corner of the underside of your ISDN LAN
Modem to stabilize your ISDN LAN Modem and prevent sliding.
Use the four clips to stack OfficeConnect units together. You can stack up to four
units. Stack small units above large units.
1. Place your existing unit on a flat surface.
Your clips fit in these positions on the side
of the unit.
2. Position a clip over one of these holes
and push it until it clicks into place.
Repeat this for the other clip position on
the same side.
3. Keeping the front of the units aligned,
rest the bottom of the new unit on the
clips' spikes. Push the clips firmly into
the new unit until they click into place.
Figure 18 Using Stacking Clips
Using Rubber Feet and Stacking Clips
Small unit
Use these
holes
Large unit
Use these
holes
Spike
