Sun Ultra 1 Series
service manual
PN 408287-051
Revision A
A PART OF THE
MARQUETTE
U N I T Y
N E T W O R K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultra 1 140 and is the answer not in the manual?

Questions and answers

Related Manuals for Sun Microsystems Ultra 1 140

Summary of Contents for Sun Microsystems Ultra 1 140

  • Page 1 Sun Ultra 1 Series service manual PN 408287-051 Revision A A PART OF THE MARQUETTE U N I T Y N E T W O R K...
  • Page 2 ã Copyright Marquette Medical Systems, Inc. 1998. All rights reserved. Trademarked names appear throughout this document. Rather than list the names and entities that own the trademarks or insert a trademark symbol with each mention of the trademarked name, the publisher states that it is using the names only for editorial purposes and to the benefit of the trademark owner with no intention of improperly using the trademark.
  • Page 3 ™ ™ Ultra 1 Series Service Manual The Network Is the Computer ™ Sun Microsystems Computer Company 2550 Garcia Avenue Mountain View, CA 94043 USA 415 960-1300 fax 415 969-9131 Part No.: 802-3819-10 Revision A, November 1995...
  • Page 4 TRADEMARKS Sun, Sun Microsystems, the Sun logo, Ultra and Solaris are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and other countries. UNIX is a registered trademark in the United States and other countries, exclusively licensed through X/Open Company, Ltd.
  • Page 5 Sun. Sun, Sun Microsystems, le logo Sun, Ultra et Solaris sont des marques déposées ou enregistrées par Sun Microsystems, Inc. aux Etats-Unis et dans certains d’autres pays. Toutes les marques SPARC, utilisées sous license, sont des marques déposées ou enregistrées de SPARC International, Inc.
  • Page 7 Revision History Revision Dash Date Comments 802-3819 August 1995 Chapter 3 and 4 are to be completed on the next revision. Some of the illustrations need to be modified. The comments for the artist are placed next to them. The board fan is being redesigned at present.
  • Page 8 Sun Ultra 1 Series Service Manual—November 1995...
  • Page 9 Contents Preface ..........xvii Part 1 —System Information 1.
  • Page 10 4.1 Power On Fails or No Video ......4.2 Power Supply Test ....... . 4.3 DSIMM Failures .

  • Page 11: Table Of Contents

    8.2 Fan Assembly ........8.3 Speaker......... . 8.4 Diskette Cable .
  • Page 12 Glossary........Glossary-1 Index .
  • Page 13 Figures Figure 1-1 Front View of the System ....... Figure 1-2 Rear View of the System.
  • Page 14 Figure 8-5 Fan Assembly ......... Figure 8-6 Replacing the Fan Assembly .
  • Page 15 Figure 9-3 Replacing the Disk Drive ....... Figure 9-4 Replacing the EMI Door ....... . Figure 9-5 Drive Bracket .
  • Page 16 Figure 10-17 Removing a DSIMM ........10-20 Figure 10-18 DSIMM Ejection Lever .
  • Page 17 Tables Table P-1 Related Documents ........xvii Table P-2 Typographic Conventions .
  • Page 18 Table B-1 Keyboard/Mouse Pin Assignments ..... . Table B-2 Serial Ports Pin Assignments ......Table 11-2 AUI Connector Pinouts.

  • Page 19: Table P-1 Related Documents

    Preface The Sun Ultra 1 Series Service Manual tells how to remove and replace system ™ ™ parts. This document applies to both Sun Ultra 1 Model 140 and Sun Ultra 1 Model 170. Chapter 11 lists the replacement parts. This document also tells ™...
  • Page 20 Table P-1 Related Documents Application Title Part Number ™ Diagnostics SunVTS User’s Guide 801-7271 ™ Diagnostics SunVTS Test Reference Manual 802-1448 ™ Diagnostics SunVTS Quick Reference Card 802-3622 Typographic Conventions The following table describes the typographic changes used in this book. Table P-2 Typographic Conventions Typeface or...

  • Page 21: Table P-3 Shell Prompts

    Procedures contained in this document must be performed by qualified service-trained maintenance providers. Only people who have been trained by ® the Sun Microsystems training facilities (or by Sun Microsystems affiliates) and have been certified as required by local and national laws are considered qualified. ™...
  • Page 22 Ordering Sun Documents The SunDocs Order Desk is a distribution center for Sun Microsystems technical documentation. It accepts all major credit cards and company purchase orders. You can order documentation in the following ways: In the U.S.A.
  • Page 23 Part 1 — System Information Product Description page 1-1...
  • Page 25 Product Description 1.1 System Unit The major components of the Sun Ultra 1 Series workstation are: • CPU system • Monitor • Sun Type-5c keyboard • Compact 1 mechanical mouse The following figures illustrate the CPU system: • Figure 1-1 shows the front view of the system. •...

  • Page 26: Figure 1-1 Front View Of The System

    1.2 System Illustrations Figure 1-1 Front View of the System Serial port A (RS-423/RS-232) Power on/ standby Power outlet Serial port B switch (Female socket) SBus slot 2 (RS-423/RS-232) SBus slot 1 SBus slot 0 TPE connector SCSI Audio Keyboard/ connector connectors Power inlet...

  • Page 27: Figure 1-3 Top View Of The System With The Cover Removed

    Cover SBus card Chassis System board DSIMMs Disk drive Power supply Speaker Diskette Drive CD-ROM or tape drive Figure 1-3 Top View of the System with the Cover Removed Product Description...
  • Page 28 Sun Ultra 1 Series Service Manual—November 1995...
  • Page 29 Part 2 — Troubleshooting SunVTS Overview page 2-1 Power-On Self-Test (POST) page 3-1 Troubleshooting Procedures page 4-1...
  • Page 31 SunVTS Overview You can use SunVTS, the Sun Validation and Test Suite, to run individual tests for verifying the configuration and functionality of most hardware controllers and devices. These are the main features of the SunVTS environment: • SunVTS kernel ( vtsk ) The SunVTS kernel controls all aspects of the testing.
  • Page 32 • Running individual tests from a command line Each individual hardware test can be run from a UNIX command line. It is useful to run a single test if you are validating a piece of hardware. The following documents provide information about SunVTS. They are available on the Solaris on Sun Hardware AnswerBook.
  • Page 33 Power-On Self-Test (POST) The Power On Self Test (POST) diagnostics reside in the system's OpenBoot PROM located on the system board. These diagnostics are useful in determining if a portion of the system has failed and should be replaced. Under normal operating conditions, POST does not run automatically when the system is powered on.
  • Page 34 The second way to start POST is by setting the diag-switch? NVRAM variable to true and then power cycling the system. To set the diag- switch? variable to true, type setenv diag-switch? true at the system ok prompt. ok setenv diag-switch? true Turn the power off, wait a few seconds, and then press the power on switch.
  • Page 35 To return to the default setting: ok setenv diag-level max To observe POST messages on serial port A, you must connect a terminal to port A or set up a tip connection to another workstation. For information about setting up tip connections, refer to the Solaris software reference manuals. 3.3 POST Progress and Error Reporting While POST is running, observe the Caps Lock key on the system keyboard.
  • Page 36 3.4 Additional Keyboard Control Commands • Stop Key If the diag-switch? variable is set to true but you want to bypass POST when the system is powered on, press and hold the Stop key on the keyboard and turn on the system power. This causes POST to be bypassed. •...

  • Page 37: Table 3-1 The Keyboard Led Patterns

    Scroll Lock Num Lock Caps Lock Compose Figure 3-2 Arrangement of the Sun Type 5-c Keyboard LEDs Table 3-1 The Keyboard LED Patterns Caps Lock Compose Scroll Lock Num Lock Bit Value Meaning of LED Pattern Blink x000 POST in progress 0000 POST successful completion 0001...
  • Page 38 Table 3-1 The Keyboard LED Patterns Caps Lock Compose Scroll Lock Num Lock Bit Value Meaning of LED Pattern 1101 Reserved 1110 Reserved 1111 Reserved 3.6 Serial Port A POST Output You can observe POST progress if you connect a terminal (or tip line) to the serial port A on the Sun Ultra 1 Series system.
  • Page 39 Hardware Power ON Button Power ON Button Power ON @(#) Sun Ultra 1 SBus 3.0 Version 0 created 1995/09/19 13:20 Probing keyboard Done %o0 = 0000.0000.0000.4001 Executing Power On SelfTest > RESET SC Control=00000000 > @(#)Sun Ultra 1 SBus POST 2.0.4 9/18/1995 03:59 PM >Date: 09/20 1995 21:14:24 >Spitfire Version 2.2 >...
  • Page 40 > DMMU Registers Access Test >DMMU Registers Access Test PASSED > DMMU TLB DATA RAM Access Test >DMMU TLB DATA RAM Access Test PASSED > DMMU TLB TAGS Access Test >DMMU TLB TAGS Access Test PASSED > IMMU Registers Access Test >IMMU Registers Access Test PASSED >...
  • Page 41 >Memory Control Register Init Test PASSED > Memory Clear Test >Memory Clear Test PASSED > Memory RAM (blk) Test >Memory RAM (blk) Test PASSED > Memory Address Line Test > Writing SIMM Pair 0 base address 00000000.00020000 > Writing SIMM Pair 2 base address 00000000.20000000 >...
  • Page 42 >CPU Softint Registers and Interrupts Test PASSED > CPU Tick and Tick Compare Registers Test >CPU Tick and Tick Compare Registers Test PASSED > CPU Interrupt Registers and Dispatch Test >WARNING Test skipped, no alternate CPU >CPU Interrupt Registers and Dispatch Test PASSED >...
  • Page 43 >Dcache Init Test PASSED > Dcache 256 Bytes Write then load Test >Dcache 256 Bytes Write then load Test PASSED > Dcache Enable Test >Dcache Enable Test PASSED >Instruction Cache Test > Icache Init >Icache Init Test PASSED > Icache Quick Test >Icache Quick Test PASSED >Forcing ECC Faults Test >...
  • Page 44 Probing Memory Done MEM BASE = 0000.0000.2000.0000 MEM SIZE = 0000.0000.0400.0000 MMUs ON Copy Done PC = 0000.01ff.f000.1a3c PC = 0000.0000.0000.1a80 Decompressing into Memory Done Size = 0000.0000.0006.84a0 ttya initialized SC Control: EWP:0 IAP:0 FATAL:0 WAKEUP:0 BXIR:0 BPOR:0 SXIR:0 SPOR:1 POR:0 Probing Memory Bank #0 16 + 16 :...
  • Page 45 Hardware Power ON Button Power ON Button Power ON @(#) Sun Ultra 1 SBus 3.0 Version 0 created 1995/09/19 13:20 Probing keyboard Done %o0 = 0000.0000.0000.2001 Executing Power On SelfTest Power On Selftest Completed Status = 0000.0000.0000.0000 ffff.ffff.f006.d268 0e66.0000.0180.1d0d Software Power ON @(#) Sun Ultra 1 SBus 3.0 Version 0 created 1995/09/19 13:20 Clearing E$ Tags Done...
  • Page 46 3-14 Sun Ultra 1 Series Service Manual—November 1995...
  • Page 47 Troubleshooting Procedures This chapter describes how to troubleshoot possible problems and includes the corrective actions you can take. Power On Fails or No Video page 4-2 Power Supply Test page 4-3 DSIMM Failures page 4-6 Hard Disk or CD-ROM Drive page 4-7 OpenBoot On-Board Diagnostics page 4-8...
  • Page 48 4.1 Power On Fails or No Video 4.1.1 Symptom The system does not power up when the power switch on the keyboard is pressed. 4.1.2 Action Check the AC power cord to be sure that it is properly connected to the system and to the wall outlet.
  • Page 49 supply may be defective. See “Power Supply Test” below. If you hear a tone and see lights on the keyboard, but the system still fails to initialize, see Section 4.8, “System Board Test,” on page 4-14. 4.1.5 Symptom No video output on the system monitor. 4.1.6 Action Check the power cord to be sure that it is connected to the monitor and to the wall outlet.

  • Page 50: Figure 4-1 Power Supply Connector J2601

    Figure 4-1 Power Supply Connector J2601 Table 4-1 J2601 Pin Descriptions Description Description +12V Thermal sensor -12V Power on Power off +3V sense +3V set Thermal sensor +3V ovp Power on reset Sun Ultra 1 Series Service Manual—November 1995...

  • Page 51: Figure 4-2 Power Supply Connector J2603

    Figure 4-2 Power Supply Connector J2603 Table 4-2 J2603 Pin Descriptions Description Description +3.3V +3.3V +3.3V +3.0V +3.0V +3.0V If any of the voltages are not present with the power supply on and are connected to the system board, replace the power supply. Troubleshooting Procedures...

  • Page 52: Table 4-3 Dsimm Physical Memory Address

    4.3 DSIMM Failures At times, the operating system, diagnostic program, or POST may not display a DSIMM location (U number) as part of the memory error message. If you encounter this situation, and the only available information is a physical memory address and failing byte (or bit), use the following table to locate the defective DSIMM.

  • Page 53: Table 4-4 Internal Drives Identification

    4.4 Hard Disk or CD-ROM Drive 4.4.1 Symptoms Disk drive read, write, or parity errors are reported by the operating system or customer applications. CD-ROM drive read or parity errors are reported by the operating system or customer applications. 4.4.2 Action Replace the drive indicated by the failure messages.
  • Page 54 ok probe-scsi Target 0 Unit 0 Disk SEAGATE ST5660N SUN1.050638DX168801 Copyright (c) 1993 Seagate All rights reserved 0000 Target 1 Unit 0 Disk SEAGATE ST5660N SUN1.050638DX168801 Copyright (c) 1993 Seagate All rights reserved 0000 Target 6 Unit 0 Removable Read Only device TOSHIBA XM- 5301TASUN4XCD173506/22/95 If the drives respond and a message is displayed, the system's SCSI controller...
  • Page 55 Example: ok watch-clock Watching the 'seconds' register of the real time clock chip. It should be 'ticking' once a second. Type any key to stop. 41 (this counter increments from 0 to 59) 4.5.2 watch-net, watch-aui, watch-tpe, watch-net-all These tests monitor broadcast Ethernet packets on the Ethernet cable(s) connected to the system.
  • Page 56 The Sun Ultra 1 Series has two types of on-board Ethernet interfaces: 10 BASE-T (also called twisted-pair Ethernet or TPE) and 10 BASE5 (also called thick ethernet or AUI). Only one Ethernet cable is connected to the back of the system.
  • Page 57 Example: ok watch-net-all /sbus@1f,0/lebuffer@1,40000/le@1,60000 Internal loopback test -- succeeded. External loopback test -- succeeded. Looking for Ethernet packets. '.' is a good packet. 'X' is a bad packet. Type any key to stop......................(keyboard key pressed here) /sbus@1f,0/ledma@e,8400010/le@e,8c00000 Using AUI Ethernet Interface Lance register test -- succeeded.

  • Page 58: Table 4-5 Selected On-Board Diagnostics Tests

    Example: ok test floppy Testing floppy disk system. A formatted disk should be in the drive. Test succeeded. 4.6 Selected On-Board Diagnostic Tests The on-board diagnostic tests that you can run on the Sun Ultra 1 Series systems are listed in Table 4-5. Table 4-5 Selected On-Board Diagnostics Tests Type of Test...
  • Page 59 Table 4-5 Selected On-Board Diagnostics Tests Type of Test Description Preparation You must attach a terminal to the This test ouputs an alphanumeric test ttya port being tested to observe the test pattern on the system's serial test ttyb output. ports (ttya = serial port A, ttyb = serial port B).
  • Page 60 Example: ok probe-scsi-all /sbus@1f,0/dma@1,81000/esp@1,80000 Target 2 Unit 0 Disk SEAGATE ST41600N SUN1.3G00286965 /sbus@1f,0/espdma@e,8400000/esp@e,8800000 Target 0 Unit 0 Disk SEAGATE ST31200W SUN1.058724 Target 1 Unit 0 Disk SEAGATE ST5660N SUN05350638 Target 6 Unit 0 Removable Read Only device TOSHIBA XM- 5301TASUN4XCD1735 4.8 System Board Test On the keyboard, press and hold the Stop and D keys.
  • Page 61 To receive additional POST failure information, you may connect a terminal to serial port A on the system. With the terminal connected, failure messages that give more information about the failure may appear. Troubleshooting Procedures 4-15...
  • Page 62 4-16 Sun Ultra 1 Series Service Manual—November 1995...
  • Page 63 Part 3 — Preparing for Service Safety and Tool Requirements page 5-1 Power On and Off page 6-1...
  • Page 65 Before servicing any part of the Sun Ultra 1 Series system, read the instructions and cautions in this section. This information explains how to work safely when servicing a Sun Microsystems product. 5.1 Safety Requirements For your protection, observe the following safety precautions when setting up your equipment: •...
  • Page 66 5.3 Safety Precautions 5.3.1 Modification to Equipment Caution – Do not make mechanical or electrical modifications to the equipment. Sun Microsystems, Inc. is not responsible for regulatory compliance of a modified Sun product. 5.3.2 Placement of a Sun Product Caution – To ensure reliable operation of your Sun product and to protect it from overheating, openings in the equipment must not be blocked or covered.
  • Page 67 5.3.4 Electrostatic Discharge Caution – The boards and hard disk drive contain electronic components that are extremely sensitive to static electricity. Ordinary amounts of static from your clothes or work environment can destroy components. Do not touch the components themselves or any metal parts. Wear a wrist strap when handling the drive assemblies, boards or cards.
  • Page 68 Electron Service Manual—November 1995...
  • Page 69 Power On and Off Powering Off the System page 6-1 Powering On the System page 6-2 6.1 Powering Off the System Before turning off system power, shut down the operating system. Failure to shut down the operating system can result in loss of data. 1.

  • Page 70: Figure 6-1 Rear View Of The System

    Power on/ standby switch Figure 6-1 Rear View of the System Warning – You must disconnect the AC power cord prior to handling the power supply. When servicing any other system components, the AC power cord should remain connected. When the system power is in the stand-by position, and the AC power cord remains connected to a power outlet, the hazardous AC voltage is still present in the power supply primary.
  • Page 71 Part 4 — Subassembly Removal and Replacement Internal Access page 7-1 Major Subassemblies page 8-1 Storage Devices page 9-1...

  • Page 73: Figure 7-1 Location Of Lock Block

    Internal Access Removing the Cover page 7-1 Attaching the Wrist Strap page 7-3 Replacing the Cover page 7-4 7.1 Removing the Cover 1. Use a Phillips screwdriver to remove the lock block (if installed) on the cover. See Figure 7-1. Lock block Figure 7-1 Location of Lock Block...

  • Page 74: Figure 7-2 Removing The Cover

    2. Loosen the captive screws securing the cover. See Figure 7-2. 3. Grasp the sides of the cover and lift up the back of the cover. After the cover clears the back panel, push the cover away from the front panel. Cover Captive screws Figure 7-2...

  • Page 75: Figure 7-3 Attaching The Wrist Strap

    7.2 Attaching the Wrist Strap 1. Unwrap the first two folds of the wrist strap and wrap the adhesive side firmly against your wrist. See Figure 7-3. 2. Peel the liner from the copper foil at the opposite end of the wrist strap and attach the copper end of the wrist strap to the top of the power supply.

  • Page 76: Figure 7-4 Replacing The Cover

    7.3 Replacing the Cover 1. Position the cover on the system as shown. See Figure 7-4. Channel (2 places) Cover Flange Captive screws Flange Figure 7-4 Replacing the Cover 2. Lower the back side of the cover until the channels on both sides of the cover align with the two flanges on the rear of the system.
  • Page 77 Major Subassemblies This chapter explains how to remove and replace the major subassemblies. Refer to the following before you remove any parts: Powering Off the System page 6-1 Removing the Cover page 7-1 Attaching the Wrist Strap page 7-3 Refer to the following after replacing any parts: Replacing the Cover page 7-4 Powering On the System...

  • Page 78: Figure 8-1 Removing The Power Supply

    8.1 Power Supply 8.1.1 Removing the Power Supply 1. Disconnect the AC power cable from the system. 2. Disconnect the DC connector from the system board at J2603. See Figure 8-1. 3. Disconnect the DC connector from the system board at J2601. 4.

  • Page 79: Figure 8-2 Replacing The Power Supply

    5. Loosen the power supply captive screw on the back panel. See Figure 8-1. 6. Push the power supply toward the front side of the chassis to disengage the mounting hooks. 7. Tilt the power supply slightly toward the system board, and lift it out of the chassis.

  • Page 80: Figure 8-3 Securing And Connecting The Power Supply

    2. Tighten the power supply captive screw on the back panel. See Figure 8-3. 3. Connect the DC connector to the peripheral power cable at P1. 4. Route and insert the DC harness through the clip on the drive bracket. 5.

  • Page 81: Fan Assembly

    8.2 Fan Assembly 8.2.1 Removing the Fan Assembly 1. Disconnect the fan power cable from the fan. See Figure 8-4. Fan power cable Figure 8-4 Fan and Power Cable Connection Major Subassemblies...

  • Page 82: Figure 8-5 Fan Assembly

    2. Press the middle tab on the fan/speaker bracket toward the center of the chassis. See Figure 8-5. 3. Grasp the fan and pull it from the fan/speaker bracket in the chassis. Fan/speaker bracket Chassis Middle tab Figure 8-5 Fan Assembly Sun Ultra 1 Series Service Manual—November 1995...

  • Page 83: Figure 8-6 Replacing The Fan Assembly

    8.2.2 Replacing the Fan Assembly 1. Position the fan assembly so the arrow on the fan faces the chassis, and the harness faces the power supply. See Figure 8-6.The arrow on the fan indicates the airflow direction. 2. Insert the fan assembly into the fan/speaker bracket in the chassis. Fan/speaker bracket Chassis Figure 8-6...

  • Page 84: Speaker

    8.3 Speaker 8.3.1 Removing the Speaker 1. Disconnect the fan power cable from the fan. See Figure 8-7. 2. Use a long-nose plier to disconnect the speaker connectors. Fan power cable Speaker Speaker connector Figure 8-7 Fan and Speaker Cable Connection 3.

  • Page 85: Figure 8-8 Removing The Fan/Speaker Bracket From The Chassis

    Fan/speaker bracket Chassis Tabs Figure 8-8 Removing the Fan/Speaker Bracket from the Chassis Major Subassemblies...

  • Page 86: Figure 8-9 Removing The Speaker From The Fan/Speaker Bracket

    5. Release the bottom part of the speaker from the fan/speaker bracket, and remove the speaker. See Figure 8-9. Fan/speaker bracket Speaker Figure 8-9 Removing the Speaker from the Fan/Speaker Bracket 8-10 Sun Ultra 1 Series Service Manual—November 1995...

  • Page 87: Figure 8-10 Replacing The Fan/Speaker Bracket Into The Chassis

    8.3.2 Replacing the Speaker 1. Position the speaker in the fan/speaker bracket. Make sure the speaker connectors are on the top. See Figure 8-10. 2. Insert the fan/speaker bracket into the chassis. Make sure the tabs are lock into the chassis to ensure proper replacement. Fan power cable Speaker cable Fan/speaker bracket...

  • Page 88: Diskette Cable

    4. Connect the fan power cable to the fan. See Figure 8-7. 8.4 Diskette Cable 8.4.1 Removing the Diskette Cable Note – If a CD-ROM or tape drive is installed in this system, begin at Step 1. If the system does not have a CD-ROM or a tape drive, go directly to Step 4. 1.

  • Page 89: Figure 8-12 Diskette Cable

    2. Remove the DC harness from the clip located on the drive bracket. See Figure 8-11. 3. Push the drive bracket toward the disk drive bay, and gently flip it over. Place it on top of the disk drive bay. See Figure 8-12.
  • Page 90 8.4.2 Replacing the Diskette Cable 1. Connect the replacement diskette cable to the diskette drive. See Figure 8-12. 2. Connect the diskette cable to the socket (marked FLOPPY) on the SCSI backplane. Note – If the system does not have a CD-ROM or a tape drive, you are done with replacing the diskette cable.

  • Page 91: Figure 8-13 Replacing The Drive Bracket

    Drive bracket Chassis Holes (3) DC harness Clip Screws Figure 8-13 Replacing the Drive Bracket 4. Route the DC harness through the clip on the side of the bracket. See Figure 8-13. 5. Replace the two drive bracket mounting screws on the chassis. Major Subassemblies 8-15...

  • Page 92: Scsi Cable/Backplane

    8.5 SCSI Cable/Backplane 8.5.1 Removing the SCSI Cable/Backplane 1. Remove the drive bracket from the chassis. See Section 9.2.1, “Removing the Bracket from the Chassis.” 2. Remove the hard disk drive assemblies. If there are two hard disk drives in the system, remove both of them. See Section 9.1.1, “Removing a Disk Drive.”...

  • Page 93: Figure 8-14 Scsi/Backplane Cable Connection

    SCSI cable SCSI backplane Screws Diskette cable Figure 8-14 SCSI/Backplane Cable Connection 6. Disconnect the SCSI cable from the system board (J2602). See Figure 8-15. 7. Pull the SCSI cable out through the disk drive bay. 8. Remove the SCSI cable from the three cable clips in the base of the chassis.

  • Page 94: Figure 8-15 Removing The Scsi Backplane

    Disk drive bay J2602 Cable clips SCSI backplane SCSI cable Figure 8-15 Removing the SCSI Backplane 9. Remove the SCSI backplane from the bracket. See Figure 8-15. 8.5.2 Replacing the SCSI Cable/Backplane 1. Route the SCSI cable under the three cable clips in the base of the chassis and through the opening near the front edge of the system board.

  • Page 95: Figure 8-16 Replacing The Scsi Backplane

    Disk drive bay SCSI back plane slot (4) 4 places Screws Diskette cable Figure 8-16 Replacing the SCSI Backplane 4. Replace the two screws to secure the backplane to the bracket. 5. Connect the peripheral power cable (P4) to the SCSI backplane (marked PWR).

  • Page 96: Peripheral Power Cable

    8.6 Peripheral Power Cable 8.6.1 Removing the Peripheral Power Cable 1. Remove the two screws securing the drive bracket to the chassis. See Figure 8-17. Clip Screws Figure 8-17 Removing the Drive Bracket 2. Remove the DC harness from the clip located on the drive bracket. See Figure 8-17.

  • Page 97: Figure 8-18 Removing The Peripheral Power Cable

    Disk drive bay SCSI cable Diskette cable Figure 8-18 Removing the Peripheral Power Cable 5. Detach the peripheral power cable from the peripherals and the fan. See Table 8-1 and Figure 8-18. Table 8-1Peripheral Power Cable Connection Connector Peripheral Diskette drive CD-ROM/tape drive SCSI backplane (PWR) Fan power connector...

  • Page 98: Figure 8-19 Peripheral Power Cable Routing On The Scsi Backplane

    6. Remove the peripheral power cable from the cable clips on the SCSI backplane. SCSI backplane Peripheral power cable Clips Figure 8-19 Peripheral Power Cable Routing on the SCSI Backplane 8.6.2 Replacing the Peripheral Power Cable 1. Connect the replacement peripheral power cable to each applicable part. See Table 8-1 and Figure 8-18.

  • Page 99: Figure 8-20 Replacing The Peripheral Power Cable

    Disk drive bay SCSI cable Diskette cable Figure 8-20 Replacing the Peripheral Power Cable 2. Route the cable through the hooks on the SCSI backplane. See Figure 8-19. 3. Position the bracket in the chassis, and slide it toward the opening in the side of the chassis.

  • Page 100: Figure 8-21 Replacing The Drive Bracket

    Bracket Chassis DC Harness Clip Screws Figure 8-21 Replacing the Drive Bracket 8-24 Sun Ultra 1 Series Service Manual—November 1995...

  • Page 101: Speaker/Led Cable

    8.7 Speaker/LED Cable 8.7.1 Removing the Speaker/LED Cable Note – If the system does not contain a CD-ROM or a tape drive, go to Step 5. 1. Remove the two screws securing the drive bracket to the chassis. See Figure 8-22. Clip Screws Figure 8-22 Removing the Drive Bracket...

  • Page 102: Figure 8-23 Placing The Bracket On Top Of The Disk Drive

    CD-ROM/ tape drive bracket Disk drive bay Figure 8-23 Placing the Bracket on Top of the Disk Drive 4. Slide the LED from the cavity, and remove the speaker/LED cable from the two cable clips. See Figure 8-24. 8-26 Sun Ultra 1 Series Service Manual—November 1995...

  • Page 103: Figure 8-24 Removing/Replacing The Speaker /Led Cable From The Chassis

    Flat side Black wire Speaker/LED cable Figure 8-24 Removing/Replacing the Speaker /LED Cable from the Chassis 5. Disconnect the cable from the speaker with a long-nose plier. See Figure 8-25. Major Subassemblies 8-27...

  • Page 104: Figure 8-25 Speaker Cable Connection

    Speaker connectors Speaker Figure 8-25 Speaker Cable Connection 6. Remove any SBus card(s) located in slot 0 and/or 1. See Section 10.3.1, “Removing an SBus Card.“ 7. Disconnect the speaker/LED cable from the system board at J2001. See Figure 8-26. 8.

  • Page 105: Figure 8-26 Speaker Connector On The System Board

    J2001 System board Speaker/LED cable Figure 8-26 Speaker Connector on the System Board 8.7.2 Replacing the Speaker/LED Cable 1. Connect the speaker/LED cable to the system board at J2001, and route the harness as shown. Secure the cable through the clips on the SCSI backplane.
  • Page 106 Note – If the system contains a CD-ROM or a tape drive, go to Steps 5 through 8. Otherwise, you are done replacing the fan/speaker cable. 5. Position the bracket assembly into the chassis, and slide it toward the opening in the side of the chassis. The hooks in the base of the chassis must lock into the holes in the bottom of the drive bracket.

  • Page 107: Figure 8-27 Replacing The Bracket To The Chassis

    Bracket Chassis Holes (3) DC Harness Clip Screws Figure 8-27 Replacing the Bracket to the Chassis Major Subassemblies 8-31...
  • Page 108 8-32 Sun Ultra 1 Series Service Manual—November 1995...

  • Page 109: Storage Devices

    Storage Devices This chapter describes how to remove and replace the storage device units. Refer to the following before you remove any part: Powering Off the System page 6-1 Removing the Cover page 7-1 Attaching the Wrist Strap page 7-3 Refer to the following after replacing any part: Replacing the Cover page 7-4...

  • Page 110: Disk Drive

    9.1 Disk Drive 9.1.1 Removing a Disk Drive 1. Remove the EMI door. a. Use a screwdriver to open up the EMI door. See Figure 9-1. b. Remove the door from the chassis. You must replace it after the new drive is installed. Chassis EMI Door Figure 9-1...

  • Page 111: Figure 9-2 Removing The Disk Drive

    3. Unlatch the drive handle and swing it open. See Figure 9-2. The connector on the back of the drive will be disconnected once the drive is ejected. Disk drive Drive handle Figure 9-2 Removing the Disk Drive 4. Hold the drive handle and pull it out to remove the drive from the chassis.

  • Page 112: Figure 9-3 Replacing The Disk Drive

    9.1.2 Replacing a Disk Drive Note – If there are two drives, install the drives into their original slots. If the drives are not installed in their original slots, the system may fail to boot, or file systems may fail to mount. 1.

  • Page 113: Figure 9-4 Replacing The Emi Door

    3. Replace the EMI door. a. Position the EMI door on the chassis. The two tabs should be hooked into the two slots. See Figure 9-4. b. Push the door in until it is flush with the chassis. Chassis door Figure 9-4 Replacing the EMI Door Storage Devices...

  • Page 114: Cd-Rom/Tape Drive

    9.2 CD-ROM/Tape Drive 9.2.1 Removing the Bracket from the Chassis 1. Remove the two screws from the chassis that secure the drive bracket. See Figure 9-5. DC harness Clip Screws Figure 9-5 Drive Bracket 2. Remove the DC harness from the clip located on the drive bracket. See Figure 9-5.

  • Page 115: Figure 9-6 Placing The Drive Bracket On Top Of The Disk Drive

    Disk drive bay SCSI cable Diskette cable Figure 9-6 Placing the Drive Bracket on Top of the Disk Drive 5. Disconnect the SCSI cable from the CD-ROM/tape drive. See Figure 9-6. 6. Disconnect the peripheral power cable from the CD-ROM/tape drive (P3), and from the diskette drive (P2) if any.
  • Page 116 9.2.2 Removing a CD-ROM/Tape Drive 1. Position the bracket on top of a flat surface, so that the CD-ROM/tape drive is flat. See Figure 9-7. Screws 4 places Bracket CD-ROM/tape drive Figure 9-7 Positioning the CD-ROM/Tape Drive 2. Remove the four screws securing the CD-ROM/tape drive to the drive bracket.

  • Page 117: Figure 9-8 Connecting The Cables From The Cd-Rom/Tape And Diskette Drive

    9.2.4 Replacing the Bracket into the Chassis 1. Place the drive bracket on top of the disk drive bay. See Figure 9-8. 2. Connect the SCSI cable to the CD-ROM/tape drive (if present). Disk drive bay SCSI cable Diskette cable Figure 9-8 Connecting the Cables from the CD-ROM/Tape and Diskette Drive 3.

  • Page 118: Figure 9-9 Positioning The Drive Bracket In The Chassis

    5. Position the bracket in the chassis, and slide it toward the opening in the side of the chassis. The hooks in the base of the chassis must lock into the holes in the bottom of the drive bracket. See Figure 9-9. Bracket Chassis Holes (3)

  • Page 119: Diskette Drive

    9.3 Diskette Drive 9.3.1 Removing a Diskette Drive 1. Remove the bracket from the chassis. See Section 9.2.1, “Removing the Bracket from the Chassis,” on page 6 and Section 9.2.2, “Removing a CD-ROM/Tape Drive,” on page 8. 2. Position the drive bracket on top of a flat surface as shown. See Figure 9-10.

  • Page 120: Figure 9-11 Positioning The Diskette Drive

    9.3.2 Replacing a Diskette Drive 1. Place the diskette drive inside the bracket. See Figure 9-11. 2. Replace the four screws. Screws 4 places Bracket Diskette drive Figure 9-11 Positioning the Diskette Drive 3. Replace the bracket into the chassis. See Section 9.2.3, “Replacing a CD-ROM/Tape Drive,”...

  • Page 121: Part 5 -System Board

    Part 5 — System Board System Board and Component Replacement page 10-1...

  • Page 123: System Board And Component Replacement

    System Board and Component Replacement This chapter provides information on removing and replacing the boards and DSIMMs and a few parts on the system board. Refer to the following before you remove any part: Powering Off the System page 6-1 Removing the Cover page 7-1 Attaching the Wrist Strap...

  • Page 124: System Board

    10.1 System Board Caution – Use an antistatic mat when working with the system board. An antistatic mat contains the cushioning needed to protect the underside components, to prevent board flexing, and to provide antistatic protection. Note – Before removing a defective system board, you must remove all DSIMMs and SBus card(s) from the defective board.

  • Page 125: Figure 10-1 Disconnecting Connectors From The System Board

    J2603 J2601 J2602 System board Figure 10-1 Disconnecting Connectors from the System Board 5. Disconnect the DC power cables from the system board at J2601 and J2603. See Figure 10-1. 6. Disconnect the speaker/LED cable from the system board at J2001. See Figure 10-2.

  • Page 126: Figure 10-2 Speaker/Led Connector On The System Board

    Speaker/LED cable J2001 Figure 10-2 Speaker/LED Connector on the System Board 7. Loosen both captive screws on the back panel. See Figure 10-3. Captive crews Figure 10-3 Captive Screws on the Back Panel 10-4 Sun Ultra 1 Series Service Manual—November 1995...

  • Page 127: Figure 10-4 Sliding The System Board Out Of The Chassis

    8. Grasp the system board and slide it out of the chassis. Chassis System board Figure 10-4 Sliding the System Board Out of the Chassis 9. Place the system board on an antistatic surface. Handle the system board by the back panel or by the edges only. 10.1.2 Replacing a System Board 1.

  • Page 128: Figure 10-5 Removing Sbus Filler Panels From The Back Panel

    Back panel SBus filler panel Locking tab (2) Figure 10-5 Removing SBus Filler Panels from the Back Panel 2. Slide the board into the rear of the chassis. Both sides of the board must fit into the slots in the plastic board guides in the base of the chassis. See Figure 10-6.

  • Page 129: Figure 10-6 Sliding The System Board Into The Chassis

    Chassis Plastic board guides (2) System board Figure 10-6 Sliding the System Board Into The Chassis 3. Tighten the two captive screws on the back panel. See Figure 10-3. 4. Connect the speaker/LED cable to the system board at J2001. See Figure 10-2.

  • Page 130: Figure 10-7 Location Of The Serial Port Jumpers

    Serial port jumpers Back panel Parallel port SCSI Audio ports J2003-J2204 NVRAM J2002 J2105 J2104 SBus slot 2 Power supply SBus slot 0 SBus slot 1 U0701 U0601 U0702 U0602 U0703 U0603 U0704 U0604 UPPER - CD-ROM drive UPPER - Hard disk drive LOWER - Diskette drive LOWER - Hard disk drive Speaker...

  • Page 131: Figure 10-8 Identifying Jumper Pins

    The jumpers can be set as either RS-423 or RS-232 mode. The jumpers are preset in RS-423 mode, the default standard for North American users. RS-232 modes are required for digital telecommunication in nations of the European Community. Jumpers are identified on the system board with silkscreened part numbers. For example, the serial port jumpers are marked J2104 and J2105.

  • Page 132: Nvram/Tod

    11. Reset the #power-cycles NVRAM variable to zero. To do this, turn the system power on, and press Stop-A after the system banner appears on the monitor. At the system ok prompt, type: ok setenv #power-cycles 0 The #power-cycles variable is incremented each time the system is power cycled.
  • Page 133 2. Hold the NVRAM/TOD carrier on both ends and lift it straight up. Gently wiggle the NVRAM/TOD as necessary. 3. Place the NVRAM/TOD with its carrier on an antistatic surface. 10.2.2 Replacing a NVRAM/TOD 1. Position the replacement NVRAM/TOD on the system board. See Figure 10-9.

  • Page 134: Sbus Card

    10.3 SBus Card Sun Ultra 1 Series has three SBus slots. See Figure 10-10 for the location of each SBus slot. System board SBus slot 1 SBus slot 2 SBus slot 0 Figure 10-10 SBus Slots Location Note – If the defective SBus card is located in slot 0, and there is another SBus card installed in slot 1, you must remove the card from slot 1 before removing the defective card from slot 0.
  • Page 135 SBus slot 1 SBus slot 0 Card retainer Figure 10-11 Removing an SBus Card from Slot 0 or 1 System Board and Component Replacement 10-13...
  • Page 136 SBus slot 2 SBus card Card retainer Figure 10-12 Removing an SBus Card from Slot 2 2. Grasp the SBus card at both corners, and pull it up to disconnect it from the socket. Caution – Avoid applying force to one end or one side of the board. It damages the connector pins.

  • Page 137: Figure 10-13 Removing The Sbus Card Extractor

    10.3.2 Replacing an SBus Card 1. Place the SBus card on an antistatic surface. 2. If required, set the jumpers or switches on the card. See your SBus product documentation. 3. Remove the SBus card extractor (if any). a. Bend one leg of the extractor slightly to the outside until the hook clears the hole in the SBus card.

  • Page 138: Figure 10-14 Replacing The Sbus Card

    Tab (2) Backplate SBus card Figure 10-14 Replacing the SBus Card 5. Align the connector with the SBus socket. Gently press the corners of the card to push the connector into the socket. Do not force the card, or you may damage the pins on the card. If the SBus card is located in SBus slot 0 or 1, see Figure 10-15.
  • Page 139 Card retainer Figure 10-15 Lock in the SBus Card Retainers, SBus Slots 0 or 1 System Board and Component Replacement 10-17...

  • Page 140: Dsimm

    SBus slot 2 SBus card Card retainer Figure 10-16 Lock in the SBus Card Retainer, SBus Slot 2 10.4 DSIMM Caution – DSIMMs are made of electronic components that are extremely sensitive to static electricity. Ordinary mounts of static from your clothes or work environment can destroy the modules.

  • Page 141: Table 10-2 Bank And Socket Locations For Dsimms

    Note – Each DSIMM removed from the system should be replaced with another DSIMM. The replacement DSIMM should have the same capacity as the defective one. It should also be inserted into the same socket as the defective one. The Sun Ultra 1 Series system must have a pair of DSIMMs in bank 0 to be able to boot.

  • Page 142: Figure 10-17 Removing A Dsimm

    10.4.1 Removing a DSIMM 1. Locate the DSIMM you want to remove on the system board. See Figure 10-17. DSIMM DSIMM sockets Lever Figure 10-17 Removing a DSIMM 2. Push the lever away from the DSIMM. See Figure 10-18. 10-20 Sun Ultra 1 Series Service Manual—November 1995...

  • Page 143: Figure 10-18 Dsimm Ejection Lever

    DSIMM DSIMM Ejection lever Figure 10-18 DSIMM Ejection Lever 3. Pull the DSIMM out of the socket. 10.4.2 Replacing a DSIMM 1. Take the replacement DSIMM from the antistatic container. 2. Position the DSIMM in the socket so the notch is on the same side as the lever.

  • Page 144: Figure 10-19 Replacing A Dsimm

    DSIMM Notch DSIMM sockets Lever Figure 10-19 Replacing a DSIMM 10-22 Sun Ultra 1 Series Service Manual—November 1995...

  • Page 145: System Board Fan

    10.5 System Board Fan 10.5.1 Removing the System Board Fan 1. Remove the two screws from the system board fan. See Figure 10-20. 2. Gently push in the middle leg of the plastic cover to unlock it from the board, and pull the plastic cover up to remove it from the system board. Screw (2) Plastic cover Board fan...

  • Page 146: Figure 10-21 Board Fan

    Board fan J0101 System board Figure 10-21 Board Fan 10.5.2 Replacing the System Board Fan 1. Position the replacement system board fan on the system board. See Figure 10-21. 2. Connect the system board fan connector to the system board at J0101. 3.

  • Page 147: Part 6 -Illustrated Parts Breakdown

    Part 6 — Illustrated Parts Breakdown Replacement Parts page 11-1...

  • Page 149: Replacement Parts

    Replacement Parts This chapter provides the replacement parts list for the Sun Ultra 1 Series system. 11.1 List of Replacement Parts This section lists part numbers and describes replacement parts for the system. Although these part numbers are correct as of the publication date of this document, they are subject to change.

  • Page 150: Table 11-1 List Of Replacements Parts

    Table 11-1 List of Replacements Parts Replacement Parts Part Number Description 501-2836 Assy, Sun Ultra 1 Model 140 system board 501-3082 Assy, Sun Ultra 1 Model 170 system board TOD/NVRAM 525-1430 TOD/NVRAM DSIMMs 501-2479 Assy, DSIMM, 16 MB 501-2622 Assy, DSIMM, 32 MB 501-2480 Assy, DSIMM, 64 MB Graphics Card...

  • Page 151: Part 7 -Appendixes, Glossary, And Index

    Part 7 — Appendixes, Glossary, and Index Product Specifications page A-1 Signal Descriptions page B-1 Functional Description page C-1...

  • Page 153: Product Specifications

    Product Specifications A.1 Physical Specifications Table A-1 Sun Ultra 1 Series Workstation Physical Specifications U.S.A. Metric Height 4.00 inches 10.15 cm Width 16.44 inches 41.75 cm Depth 17.44 inches 44.30 cm Weight range 21.0 to 27.5 lbs 9.55 to 12.50 kg...

  • Page 154: Table A-3 Environmental Limits

    A.2 Electrical Specifications Table A-2 AC/DC Power Supply Specifications Parameter Description Value Input Voltage range 100 to 240 VAC Current, maximum 3.1 to 1.5A Current frequency range 47 to 63 Hz Output +5V, 18A +3.3V, 12 A +2.5 to 3.6 V, 12 to 8.3 A +12V, 5.1 A -12V, 0.3 A Input Power rating...

  • Page 155: Figure B-1 Keyboard/Mouse Connector

    Signal Descriptions B.1 Keyboard/Mouse and Serial Port B.1.1 Keyboard/Mouse This connector is located on the system back panel. Figure B-1 Keyboard/Mouse Connector Table B-1 Keyboard/Mouse Pin Assignments Signal Name Description Signal Name Description Ground kbd-txd Keyboard transmit data Ground kbd-rxd Keyboard receive data kbd-pwer Keyboard power...

  • Page 156: Table B-2 Serial Ports Pin Assignments

    B.1.2 Serial Ports A and B (RS-422/RS-232) These connectors are located on the back panel of system board. Figure B-2 Serial Ports A and B Connector Table B-2 Serial Ports Pin Assignments Signal Name Description Signal Name Description Not connected none Not connected none...

  • Page 157: Signal Descriptions

    B.2 AUI (Attachment Unit Interface) Connector This connector is located on the back panel of the system board. Figure B-3 AUI Connector Table 11-2 AUI Connector Pinouts Function AUI_CI+ AUI_DO+ AUI_DI+ AUI_CI- AUI_DO- AUI_DI- +12 VDC Signal Descriptions...

  • Page 158: Figure B-4 Tpe Connector

    B.3 TPE Connector This connector is located on the back panel of the system board. 12345678 RJ45 Figure B-4 TPE Connector Table B-3 TPE Pin Assignments Signal Name Description Signal Name Description tpe0 Transmit No connect tpe1 Transmit tpe3 Receive tpe2 Receive No connect...

  • Page 159: Figure B-5 Scsi Connector

    B.4 SCSI This connector is located on the back panel of the system board. Figure B-5 SCSI Connector Table B-4 SCSI Pin Assignments Signal Name Description Signal Name Description Ground scsi dat 0 SCSI data 0 Ground scsi dat 1 SCSI data 1 Ground scsi dat 2...
  • Page 160 Table B-4 SCSI Pin Assignments Signal Name Description Signal Name Description Ground scsi msg l SCSI message Ground scsi sel l SCSI select Ground scsi cd l SCSI command Ground scsi req l SCSI request Ground scsi io l SCSI input/output Sun Ultra 1 Series Service Manual—November 1995...

  • Page 161: Table B-5 Audio Pin Assignments

    B.5 Audio Connectors The Audio connectors are located on the back panel of the system board. Headphones—Line-out—Line-in—Microphone Figure B-6 Audio Ports Connector Table B-5 Audio Pin Assignments Headphones Line Out Line In Microphone Left channel Left channel Left channel Left channel Ring (center) Right channel Right channel...

  • Page 162: Figure B-7 Parallel Port Connector

    B.6 Parallel Port This Parallel Port connector is located on the back panel of the system board. Figure B-7 Parallel Port Connector Table 11-3 Parallel Connector Pinouts Description Description nStrobe nAutoFd Data[1] nFault Data[2] nInit Data[3] nSelectln Data[4] Signal Ground Data[5] Signal Ground Data[6]...

  • Page 163: Functional Description

    Functional Description System Features page C-1 Sun Ultra 1 Series System Block Diagram page C-2 System Board Block Diagram page C-3 C.1 System Features The Sun Ultra 1 Series system conforms to the Sun4u system architecture. The ™ CPU board contains a single UltraSPARC microprocessor.
  • Page 164 C.2 Sun Ultra 1 Series System Block Diagram Figure C-1 shows a block diagram of the Sun Ultra 1 Series system. Back panel Parallel port SCSI Audio ports J2003-J2204 NVRAM J2002 J2105 J2104 Power supply SBus slot 2 SBus slot 0 SBus slot 1 U0701 U0601...

  • Page 165: Figure C-2 Sun Ultra 1 Series System Board Block Diagram

    C.3 System Board Block Diagram Figure C-2 shows a block diagram of the Sun Ultra 1 Series main logic board Address UltraSPARC SC_UP SBus slots SYSIO SBus 25MHz SLAVIO Macio AUDIO SERIAL SCSI ENET EBUS PARALLEL DRAM Figure C-2 Sun Ultra 1 Series System Board Block Diagram Functional Description...
  • Page 166 Sun Ultra 1 Series Service Manual—November 1995...
  • Page 167 Glossary address Refers to a location within a computer system memory. The word location is a synonym. Reference is usually made to an address for the purpose of retrieving or storing information. The BMX (Buffered Crossbar Chip) is the hub of all data transfers in the system.
  • Page 168 DRAM Dynamic Random Access Memory. DSIMM DRAM Single Inline Memory Module. A small printed circuit card that contains dynamic random access memory (DRAM) chips. An acronym for Electrostatic Magnetic Interference. Ethernet A type of network hardware that allows communication between systems connected directly together by transceiver taps, transceiver cables, and either a coaxial or twisted-pair cables.
  • Page 169 SunVTS Sun Validation and Test Suite is a diagnostic tool designed to stress test Sun hardware. Within this environment, a user can run individual tests designed to validate Sun supported piece of hardware. It also allows programmers to develop their own tests and run them on SunVTS interface. SYSIO Is a bridge chip between UPA and the SBus.It also acts as the IO hub providing features such as the IOMMU and streaming buffers to speed up sequential IO...
  • Page 170 Glossary-4 Sun Ultra 1 Series Service Manual—November 1995...
  • Page 171 Index audio connector, B-7 diagnostic test on-board, 4-12 AUI connector, B-3 disk drive error, 4-7 removing, 9-2 bracket replacing, 9-4 removing, 9-6 diskette cable, 9-9 replacing, 9-9 removing, 8-12 replacing, 8-14 diskette drive removing, 9-11 card retainer, 10-16 replacing, 9-12 CD-ROM drive handle, 9-3, 9-4 error, 4-7...
  • Page 172 hard disk drive, 4-7 peripheral cable connection, 8-21 extractor physical specifications, A-1 SBus card, 10-15 POST error reporting, 3-3 how to start, 3-1 max and min level, 3-2 failures, 4-6 progress, 3-3 fan assembly POST output removing, 8-5 serial port A, 3-6 replacing, 8-7 power fan/speaker bracket, 8-8, 8-11...
  • Page 173 replacement, 11-2 electrical, A-2 physical, A-1 replacing bracket, 9-9 symbols, 5-1 CD-ROM, 9-8 system board cover, 7-4 removing, 10-2 disk drive, 9-4 replacing, 10-5 diskette cable, 8-14 system board fan diskette drive, 9-12 removing, 10-23 DSIMM, 10-21 replacing, 10-24 EMI door, 9-5 system board test, 4-14 fan assembly, 8-7 peripheral cable, 8-22...
  • Page 174 Index-4 Sun Ultra 1 Series Service Manual—November 1995...
  • Page 175 Reader Comment Card Your comments and suggestions are important to us. Let us know what you think about the Sun Ultra 1 Series Service Manual, part number 802-3819-10 . Are the instructions easy to follow? Please explain Are the illustrations helpful? Please explain Which format do you prefer to use? Hardcopy...
