ETC Installation Guide
Pro One-Cell
D4 Series Emergency Driver Current Configuration
See D4 Series Driver Current Configuration on page 17
current in D4 non-emergency drivers.
Note:
D4 Series Constant Current (CC) drivers can be configured for 400 mA or 600 mA output using the
four switch blocks shown in the illustration of the
Outputs
Each of the four switch blocks controls one output.
Switch block S1 controls LED1.
•
Switch block S2 controls LED2.
•
Switch block S3 controls LED3.
•
Switch block S4 controls LED4.
•
Switch Functions
Each switch block has six switches.
Note:
Switch 1 sets the current output threshold.
•
ON = 400 mA, OFF = 600 mA.
Switches 2 through 5 control the DMX channel assigned to the output.
•
Switch 6 enables emergency functionality.
•
Switches 2 through 5 are factory set to allow each output to be controlled by an individual
DMX address. ETC recommends leaving the DMX channel switches (positions 2 through 5) at their
factory settings and using the ArcSystem Configuration Software or RDM settings to control the
behavior of each output.

Complete Installation

Now that you have completed wiring the power to your emergency system driver, standard
installation procedures can be completed. Refer to the following sections once power wiring is
completed:
Luminaire Connection to Driver on page 15
•
DMX In and DMX Thru on page 16
•
Installing One-Cell Recessed Luminaires on page 18
•
Installing One-Cell Yoke-Mounted Luminaires on page 18
•
Pro One-Cell
Do not change the switch settings on a D4 Constant Voltage (CV) model driver.
Do not change the switch 1 settings on a D4 Constant Voltage (CV) model driver.
for information on configuring the driver
D4 Emergency Driver on page 20
Page 22 of 29
.
