IconMaster Installation and Configuration Manual
Any aux buses that are not enabled will not appear in the LCD button
display on the RCP, and will be grayed out in the ISCP.
The router source levels will be set automatically, to the defaults in
Figure 8-11.
3. To change the name of a router source configuration, click on the
appropriate name box, and then enter a new name for the associated source
(a maximum of 8 characters is allowed).
4. To change the level assigned to each Aux bus, click on the appropriate level
box, and then choose the required level from the drop-down box. There is a
maximum of 16 levels (0 to 15). Selecting Unused will disable an Aux bus
from use.
5. The number in the Dest column should be set to the router destination being
used for each of the Aux buses. To change the assignment, double-click on
the Dest field to be changed, and then enter the new assignment. Press
Enter to complete the change.
Any router input can be assigned to any of the 12 Aux bus sources (labeled Src
1 to Src 12). This is possible for each aux bus independently. To change the
assignment, double-click the Src field to be changed, and then enter the new
assignment. Press Enter to complete the change.
Note
It is strongly encouraged that any Aux busses that are not in use
be disabled using the Enable checkbox at the top of each Aux bus
page, for Aux busses 1–12.
Chapter 8: Configuring IconMaster
167
