Compaq WL110 User Manual page 91

3. Select the
Wireless Interfaces
4. Click the
Security
Figure 7-3).
5. Select the option
Enter up to 4 different keys to decrypt data received via the wireless
interface
Select one of these keys to encrypt wireless data that is to be transmitted
via the wireless interface.
6. Click to return to the
OK
7. Click again to save the configuration to the Access Point and to return to
OK
the main AP Manager window.
The Access Point will now reboot.
Optionally you can choose to configure your Access Point to allow or deny non-
encrypted data.
WEP Encryption Key Values
If you select to enable encryption you may choose to enter up to the following
encryption keys.
For the 128-bit RC4 encryption that supports 64-bit WEP based on RC4
encryption algorithm are either:
5-digit alphanumerical value in the range of "a-z" and "0-9"
Example: SECU1
A 10-digit hexadecimal value, preceded by the characters "0x" (zero x).
Example: 0xABCD1234FE
For the 128-bit encryption based on the RC4 encryption algorithm are either:
13-digit alphanumerical value in the range of "a-z" and "0-9"
Example: SECURE1234567
A 26 -digit hexadecimal value, preceded by the characters "0x" (zero x).
Example: 0x1234567890ABCDEF1234567890
Hexadecimal strings that are not preceded by the leading "0x" will be
interpreted as alphanumerical string.
Note: The WEP key values you enter will remain visible only when you enter
the character strings. As soon as you close the Security Setup window,
the values will be stored in hidden characters: i.e. a next time the
Security Setup window will be displayed, you will not be able to read
the WEP key values anymore. You are advised to write down the values
you enter, prior to closing the window.
WEP Transmit Key value
If you enable WEP encryption, you can select one key for wireless data
transmissions from the list of WEP encryption key values. You can only select a
transmit key that has a correct WEP encryption key value assigned. In case you
tab.
button to view the Wireless Security Setup window (see
to enable encryption, and:
Enable Encryption
Wireless Interfaces
tab.
Security 7-9
