Compaq Fast Ethernet Module NC3133 Quickspecs

M
O D E L S
Compaq NC3133
Fast Ethernet Module
100 FX Upgrade Module for
NC3131
338456-B25
With the NC3133 100 FX
Upgrade Module, Compaq
introduces 100 Mbps support for
environments requiring the
additional distance and security
available through fiber optic
cabling.
Optional Upgrade Modules
Fast Ethernet
NC3132: Dual 10/100
Upgrade Module
338456-B22
Gigabit
NC6132: 1000 SX
Upgrade Module
338456-B23
NC6133: 1000 LX
Upgrade Module
338456-B24
Fast Ethernet NIC Family
NC3120: PCI, 10/100
317600-B21
NC3123: PCI, 10/100 WOL
174830-B21
NC3122: PCI Dual 10/100
317450-B21
NC3131: Fast Ethernet NIC 64
PCI Dual Base 10/100
338456-B21
Gigabit Ethernet NIC Family
NC6134: 1000 SX 64 PCI
Gigabit NIC
174818-B21
11-19
Q S
UICK PECS
. .
. . Overview
. .
. .
The NC3133, when plugged into a NC3131, adds a 100 Mbps Fast Ethernet network connection over fiber optic cable
. .
. .
for server backbones and campus-wide connectivity. This upgrade module is ideal for sites with extended distance
. .
. . requirements, the need for added security, or EMI protection.
. .
. .
. .
P
. . E R F O R M A N C E
. .
. .
32-bit Bus-mastering
. .
. .
. .
The NC3133 offers the highest level 100 Mbps data transfer method available between the network and 32-bit slots
. .
. . for high performance and low CPU utilization. The NC3133 uses bus-mastering technology to maximize throughput
. .
and minimize CPU utilization.
. .
. .
. .
Port Bonding
. .
. .
. .
Adaptive Load Balancing (ALB) and Cisco's Fast EtherChannel are two port bonding methods supported by the
. .
NC3133. ALB provides both failover and balancing of transmit traffic across all NICs for increased performance. For
. .
. .
even higher performance, Cisco's Fast EtherChannel provides port failover and balancing of transmit and receive
. .
. .
traffic across all NICs when used with a Fast EtherChannel enabled switch.
. .
. .
. .
S / R
. .
E C U R I T Y E L I A B I L I T Y
. .
. .
Network Fault Tolerance (NFT)
. .
. .
. .
NFT support, sometimes called "NIC Redundancy" or "failover," enables the NIC to keep an active connection if
. .
. .
another NIC, switch or hub link fails by automatically switching to a backup NIC.
. .
. .
PCI Hot Plug
. .
. .
. .
The NC3133 includes PCI Hot Plug support, which enables it to be replaced or added to a server without powering
. .
. . down the system. This feature provides increased system availability and non-stop serviceability in business-critical
. .
computing environments.
. .
. .
. .
. .
N M
E T W O R K A N A G E M E N T
. .
. .
. .
Standards-based
. .
. .
. . The NC3133 supports the following industry network management standards to work with a broad spectrum of
. .
software utilities.
. .
. .
SNMP
. .
. .
DMI 2.0
. .
. .
Web-Based Enterprise Management (WBEM)
. .
. .
. . Server Integration
. .
. . Compaq's SmartStart ®
. .
part of the SmartStart configuration process. Compaq Insight Manager
. .
. .
port bonded teams, and can collect and report SNMP statistics on the NIC events. The Compaq Network
. .
. . Management System (CNMS) can also collect and report SNMP statistics on the NC3133.
. .
. . Integrated Management Log (IML) support is provided by the NC3133 for critical event logging on Compaq servers.
. .
. .
Diagnostic LEDs
. .
. .
LEDs show link integrity and network activity for easy troubleshooting.
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
DA-10306-01-001
configuration utility includes setup support for the NC3133 so the NIC can be configured as
Compaq NC3133
Fast Ethernet Module
can recognize the NC3133 individually or in
®
100 FX
