Two connectors
to same
D-ring.
NO.
Incompatible
or irregular
application,
which may
increase risk
of roll-out.
NO.
Correct Anchorage Positioning:
This chart details allowable working zones required
to reduce risk of swing falls and improper side loading.
ALWAYS adhere to information specified by chart.
Anchor Distance
Working Distance
From
Along Roof Edge
Leading Edge (Y)
(Either Direction) (X)
6'
10'
9' - 9"
15'
11' - 7"
20'
13' - 3"
25'
14' - 6"
30'
16'
35'
17' - 2"
40'
18' - 3"
45'
19' - 4"
50'
19' - 10"
55'
21' - 4"
60'
22' - 3"
For example, if the anchorage connector is 6' from the leading
edge (Y), the working distance (X) is 8' in each direction from
the perpendicular, which translates to a 53° working angle.

Components and Specifications

Type A anchorage connector.
Minimum permitted service
temperature: -30° F.
5,000 lb. MBS
(minimum breaking strength).
Materials: Stainless steel,
aluminum, nickel plated steel,
and polyester.
3
Working Angle
From
Perpendicular (Ø)
8'
53°
45°
38°
33°
30°
28°
26°
24°
23°
21°
21°
21°
High Strength Bar
L
Safety Locks and
Clamp Toggles
Ø: Total Working Angle
X: Working Distance
Along Leading Edge
Y: Distance From
Leading Edge
Y
X
Leading Edge
D-ring
Application
that places
load on gate.
NO.
Connector
directly to
horizontal
NO.
lifeline.
ø
X
Beam Rollers
End Screw Cap (L/R)
R
Anchor Strap
