Installation Guide
ELISE2
LED Indication
Colour
Green
Orange
Orange
Orange
Orange
Orange
Orange
Red
Red
Red
Red
Red
Red
1
Fail safe mode is indicated, even if SW3 pin 2 is not set to ON, if the application on
ELISE2 is not completely installed or when the application part of the Compact Flash is
erased.
2
When ELISE2 is in Network setup mode, this will always be indicated and override LED
indications of other simultaneously activated modes, for example Image installation mode.
3
Starting up mode is indicated during start of applications or if an application has lost
connection to a required resource, for example A-bus.
3.6

Administration and Authentication

Administration on ELISE2 is done from a web browser. In order to access the
administration pages a user name and password have to be given.
IMPORTANT: The default passwords have to be changed, else anyone with knowledge
2005-06-15 / Ver.G
Each segment = 100 ms
of a password and the IP address can access the administration web pages
and make changes.
Status
OK. Running
1
Fail-safe mode
2
Network setup mode
Image installation mode
3
Starting up
Power up
Restart
Halted (auto. restart after 10 min.)
Unlicensed mode
Low voltage
Licence error
Watch-dog reset
Shut-down
Memory error (3 s ON / 3 s OFF)
Network error (IP interface initiation error)
Module key error (Module key not found)
TD 92232GB
7
