Installation Guide
ELISE2
Connectors
J2
J5
J6
J7
J8
J9, J10
J11
J12, J13
J14
J16
J20
J22
J24
Jumper points and push buttons
J1
J4
J15
S1, S2
S3
S4, S5
SW4
Switches
SW2
SW3
Module key and Backup battery
IC1
IC2
IC24
BAT1
LEDs
LED1
LED2-LED5
LED6
LED7
2005-06-15 / Ver.G
Connector for the Compact Flash
Connection of supply voltage
For connection of RS422 communication
Modular jack (RJ45) for connection of RS232 communication. RS232:3
Modular jack (RJ45) for connection of RS232 communication. RS232:2
LON/GP Interface Connector
Modular jack (RJ45) for connection of RS232 communication. RS232:1
Modular jacks (RJ45) for connection of System 900 bus cabling
Connector where an error relay output is available.
Connects AUX Input and AUX Output
For connection of 10baseT or 100baseT Ethernet TCP/IP network
For internal use only
For connection of A or B-bus from System 900 when modular system bus
cable is not used.
Jumper that activates the backup battery. (Jumper pin 2-3 to activate).
For grounding and production test
Jumper that determines if the Error relay output should be active when
the relay operates or is released. Normally set to 1-2 to select operating.
Jumper points for selection of A or B-bus
For internal use only
Jumper points used when ELISE2 controls the communication on the
A/B-bus.
Reset button for CPU
Module address selector switch for A or B-bus. If the setting of SW2 is
changed, the ELISE2 module detects this automatically and will reconnect
to the System 900 with the new address (it takes approximately 30 s).
Selector switch for operating mode
CPU
On-board flash
Module key
Backup battery
Function indicator with green, orange and red indication
Application dependent functionality. See documentation on the
application for description.
Communication on the Ethernet
Ethernet speed indicator. ON 100 Mbit/s, OFF 10 Mbit/s
TD 92232GB
3
