Appendix A: LON Piggy Back Circuit Board (LPB)

Connectors and Jumper Points
J1
J2
J3
J4
Push button
SW1
Micro Controllers and others
IC1
IC3
IC9
LEDs
LED1
LED2
LED3
LED4
LED5
LED6
2005-06-15 / Ver.G
J3
IC1
J2
Connection for the teleCARE M LON (only use terminals 1 and 2)
Connector for In System Programming (ISP) of the flash micro controller
Male connector to be put on J9 on ELISE2 circuit board. Pin 12 cut off
Male connector to be put on J10 on ELISE2 circuit board
For service
Flash memory
Neuron micro controller
PIC flash micro controller
LON Rx
LON Tx
See table for LED3 in
Rx data transfer
Tx data transfer
See table for LED6 in
IC3
IC9
LED
1 2 3 4 5 6
Status Indication of LPB
Status Indication of LPB
TD 92232GB
J4
SW1
J1
on page 29
on page 29
