Installation Guide
ELISE2
5.3

Replacing an Image on the Compact Flash

The complete Compact Flash image has to be replaced if the ELISE2 operating system has
been updated. When a new image is installed, all information on the Compact Flash will
be replaced. It is recommended to take a backup of the parameters before the image is
installed in order to be able to recover the unit to original setup.
1 Open the page xxx.xxx.xxx.xxx/system.
2 Press "Software". Navigate to "Install Image". Follow the instructions on the page.
Note that it will take some time to install the new image. The time is dependent of
the size of the image and the type of connection to the ELISE2.
Note: The .img file must be used to update the complete image on the Compact Flash.
It is possible to replace the image over a remote connection. However, note that it is not
possible to replace the image on the ELISE2 that handles the remote connection.
5.4

Installing an Image on an empty Compact Flash

An image can also be installed on an empty Compact Flash.
1 Set section one and four in SW3 to ON, to set the ELISE2 in "Network setup mode"
and "Image installation mode".
2 Perform a power down of the unit and then restart it, see
Restart of ELISE2
3 Use the program "Route to ELISE" to connect to the ELISE2. A web page where a
new image can be installed will open.
4 Select the image to install. Note that it will take some time to install the new image.
The time is dependent of the size of the image and the type of connection to the
ELISE2.
Note: The .img file must be used to update the complete image on the Compact
Flash.
5 Set section four in SW3 to OFF and press "Reboot" on the displayed web page, to
leave "Image installation mode".
6 Setup the parameters according to instructions in
Parameters
5.5

Updating the Software Licence

1 Open the page xxx.xxx.xxx.xxx/admin and press "General".
2 Enter the new licence, and press "Activate".
2005-06-15 / Ver.G
on page 4.
on page 20 or recover parameters from a backup file.
TD 92232GB
3.2 Power Down and
4.12 Setup of Network
26
