Installation Guide
ELISE2
5 Connect cables to the screw connector J1. Use max. 2 x 0.8 mm wires per
connector. Strip the outer sheath of the cables to a length of about 10 cm. Only use
pins 1 and 2 for connection of the LON bus in/out. (Pins 3 and 4 can be used for
connection of other LON devices, for example SLA). See
Max. 2 x 0.8 mm ø wire
at each connector. Strip 10 cm
Figure 22. Cabling of screw connector J1
6 Replace all removed connectors
7 Close the cover and restart ELISE2, see
page 4.
2005-06-15 / Ver.G
J1
1 2 3 4
teleCARE M LON
3.2 Power Down and Restart of ELISE2
TD 92232GB
figure 22 below.
033
on
30
