Opening The Housing - ASCOM ELISE2 Installation Manual

Installation Guide
ELISE2
Note: Only install one ELISE2 module at a time, otherwise problems might occur during IP
addressing.
Installation Procedure
1 Read chapters 4.1 and 4.2 before starting the installation.
2 At delivery ELISE2 is configured for system communication on the A-bus. If modular
system bus cabling is used and the B-bus shall be used for system communication,
follow the instructions in
3 At delivery, the ELISE2 is configured to be connected to a Central Unit on the A/B-
bus. If the ELISE2 should control the communication on the A/B-bus, follow
instructions in
11.
4 Mount ELISE2 on the wall, follow instructions in
4.6 Mounting Together with Other Units
5 Set the system bus address, follow instructions in
page 14.
6 Connect the system bus, follow instructions in
page 14 and
7 Optionally connect outputs and inputs described in
page 17.
8 Activate the battery, follow instructions in
9 Perform a network parameter setup of ELISE2, follow instructions in
Network Parameters
10 Connect Ethernet connector to the Local Area Network, follow instructions in
Connection of Ethernet
11 Perform a test of the installation, follow the instructions in
Procedure
12 Continue with additional parameter setup for the unit according to chapter
4.15-
13 Make a backup copy of all parameters.
4.1

Opening the Housing

Use a screwdriver or similar to release the cover by applying a light pressure to the two
snap catches (1) and remove the cover (2).
Figure 5. Opening the ELISE2 housing.
2005-06-15 / Ver.G
4.3 Selection of A or B-bus
4.4 ELISE2 controlling the Communication on the A/B-bus
4.9 Connection of Supply Voltage
on page 20.
on page 22.
on page 22.
4.17 and respective software application documentation.
1
1
on page 11.
4.5 Mounting on page 13 and
on page 13.
4.7 System 900 Addressing
4.8 Connection of System Bus
on page 16.
4.10 Additional Connections
4.11 Activation of Battery
4.14 Installation Test
TD 92232GB
on page
on
on
on
on page 19.
4.12 Setup of
4.13
9
