Connection
This chapter provides all necessary information of the peripheral's connections,
switches and indicators. Always power off the board before you install the peripherals.

3-1 List of Connectors

CBT1: Li 3V Battery 1x2pin (1.25mm) Wafer
CA3: Line-out/Line-in/Mic-in 2x5 pin (2.0mm) Wafer
CALR1: Amplifi er 1x4 pin (1.25mm) Wafer
CC1 : COM 2x5pin (2.0mm) wafer
CC2 : COM 2x5pin (2.0mm) wafer
CFP1: Front Panel connector 2x5pin (2.0mm) wafer
CIO1: DIO 2x5pin (2.0mm) Wafer
CL1 : LAN port 1 RJ45 Connector
CL2 : LAN port 2 RJ45 Connector
CL11 : LAN port 1 RJ45 2x4pin (2.0mm) wafer(option)
CL21 : LAN port 2 RJ45 2x4pin (2.0mm) wafer(option)
CO1: I
CPI1: DC 12V-IN 1x4pin (2.0mm) Red wafer connector
CPO1: +12V/+5V power output 1x4pin (2.0mm) Black wafer connector
CU12: Dual USB3.0 Type A connector
CU3: USB2.0 Type A connector
CU4: USB3.0 Type A connector
CU5: USB 2.0 port 1x4pin (1.25mm) Wafer
CU6: USB 2.0 port 1x4pin (1.25mm) Wafer
CU7: USB 2.0 port 1x4pin (1.25mm) Wafer
LVDS1: LVDS 2x15pin (1.25mm) connector
CPP1: BKL power 1x5pin (2.0mm) Wafer
CT1: TOUCH 2x5pin (2.0mm) Wafer
SATA1: One SATA connector 7pin
MPCE1: Full size mini card port 1 sockets 52pin
MPCE2: Full size mini card port 2 sockets 52pin
Chapter-3
2
C Bus 1x4pin (1.25mm) Wafer
25
